How to Configure UFW Firewall

Uncomplicated Firewall (UFW) is the default firewall configuration tool on Ubuntu and most of the debian based distributions. It offers a simplified interface for managing complex iptables rules, making it more straightforward to control incoming and outgoing traffic.

This article explains the most commonly used UFW commands to help secure your server.

Prerequisites

Before you begin, you need to:

• Have access to a Linux server with UFW installed as a non-root user with sudo privileges.

Check UFW Status

Check the status of the firewall. By default, UFW is active on Vultr Compute instances..

$ sudo ufw status

• If the output displays the status as inactive, run the below command to enable UFW.

  console Copy

  $ sudo ufw enable && sudo ufw allow ssh


  Explain Code

  The command above enables UFW and instantly adds a rule to allow SSH, ensuring your session stays active.

Manage the Firewall

• Enable UFW

  Activate the UFW firewall to start enforcing the configured rules.

  console Copy

  $ sudo ufw enable


  Explain Code

• Disable UFW

  To disable the firewall and stop enforcing rules.

  console Copy

  $ sudo ufw disable


  Explain Code

• Reset UFW

  To delete all existing rules and restore UFW to its default inactive state.

  console Copy

  $ sudo ufw reset


  Explain Code

Common UFW Configuration Examples

To guard your servers against unauthorized access and reduce exposure to potential threats, it's important to allow only the traffic necessary for your applications. This section demonstrates practical UFW configurations for common server scenarios, helping you build a secure and controlled network environment by explicitly permitting essential services while blocking all other unsolicited connections.

Allow SSH and Deny All Other Inbound Traffic

In this section, you configure UFW to allow only SSH connections and block all other inbound traffic. This setup provides a secure baseline for newly deployed servers that do not yet run public-facing services.

1. Set the default policies to deny all incoming traffic and allow all outgoing traffic.

   console Copy

   $ sudo ufw default deny incoming
   $ sudo ufw default allow outgoing


   Explain Code

2. Allow SSH connections.

   console Copy

   $ sudo ufw allow ssh


   Explain Code

3. View the ufw status.

   console Copy

   $ sudo sudo ufw status


   Explain Code

   Output:

   Status: active

   To                         Action      From
   --                         ------      ----
   22/tcp                     ALLOW       Anywhere
   22/tcp (v6)                ALLOW       Anywhere (v6)

Allow Web Server Traffic

To host websites or web applications, your server must be accessible over standard web ports. This configuration allows traffic for essential services HTTP (port 80), and HTTPS (port 443), while blocking all other unsolicited connections.

1. Allow HTTP traffic.

   console Copy

   $ sudo ufw allow http


   Explain Code

2. Allow HTTPS traffic.

   console Copy

   $ sudo ufw allow https


   Explain Code

3. View the ufw status.

   console Copy

   $ sudo sudo ufw status


   Explain Code

   Output:

   Status: active

   To                         Action      From
   --                         ------      ----
   22/tcp                     ALLOW       Anywhere
   80/tcp                     ALLOW       Anywhere
   443                        ALLOW       Anywhere
   ......

Allow a Specific Port

To expose a specific service running on your server, you can allow traffic on its associated port. This is useful for enabling access to applications like databases, VPNs, or custom services.

• To allow traffic on a specific port using the TCP protocol, such as MySQL (port 3306):

  console Copy

  $ sudo ufw allow 3306/tcp


  Explain Code

  The command above allows the TCP traffic on port 3306.

• To allow traffic on a specific port using the UDP protocol, such as for an OpenVPN server (port 1194):

  console Copy

  $ sudo ufw allow 1194/udp


  Explain Code

  The command above allows the UDP traffic on port 1194.

Allow a Specific IP Address

In cases where you want to limit access to specific, trusted sources such as office networks, VPN gateways, or monitoring systems you can allow traffic from a specific IP address.

• To allow all traffic from a trusted IP:

  console Copy

  $ sudo ufw allow from 192.0.2.4


  Explain Code

• To allow a trusted IP access to a specific port (e.g., SSH):

  console Copy

  $ sudo ufw allow from 203.0.113.100 to any port 22


  Explain Code

Delete a UFW Rule

If you no longer need a rule or have added one incorrectly, you can remove it using its rule number.

1. Run the below command to list all the active rules with numbering:

   console Copy

   $ sudo ufw status numbered


   Explain Code

2. Delete a rule using it's number.

   console Copy

   $ sudo ufw delete 2


   Explain Code

Conclusion

In this article, you have explored how to secure your Linux server using UFW. You configured default firewall policies, allowed essential services like SSH and web traffic, opened specific ports and protocols, whitelisted trusted IP addresses, and also have deleted unwanted firewall rules.
