How to Migrate Google Cloud Persistent Disks to Vultr Block Storage

Vultr Block Storage is a high performance, highly available, and scalable storage solution that allows you to expand its storage capacity independently from its compute instance. Google Cloud Platform (GCP) persistent disks are block storage volumes you can mount on virtual machines and store data similar to Vultr Block Storage volumes.

Follow this guide to migrate Google Cloud Platform (GCP) persistent disks to Vultr Block Storage. You will set up a migration environment, transfer your data, and verify the integrity of the transferred files using Rsync.

Prerequisites

Before you begin, you need to:

• Have access to an Ubuntu 24.04 LTS based Google Compute Engine instance as a non-root sudo user.
• Have an existing Persistent Disk that's attached to your Google Compute Engine instance.
• Have access to an Ubuntu 24.04 LTS based Vultr Cloud Compute instance as a non-root sudo user.
• Attach a Vultr Block Storage volume to the instance.

Set Up the Migration Environment

In this section, you'll prepare the Ubuntu instances of both, your Vultr account and your Google Cloud Project, for the data migration. To prepare your GCP environment, open the SSH session of your Compute Engine instance in your browser window and follow these steps:

1. List the filesystem devices attached to your instance.

   CONSOLE

   Copy

   $ lsblk -f

   Explain Code

   Powered by Vultr AgentBeta

   Below is an example output:

   NAME    FSTYPE FSVER LABEL           UUID                                 FSAVAIL FSUSE% MOUNTPOINTS
   loop0                                                                           0   100% /snap/core20/2434
   loop1                                                                           0   100% /snap/google-cloud-cli/307
   loop2                                                                           0   100% /snap/snapd/23545
   sda
   ├─sda1  ext4   1.0   cloudimg-rootfs 95c27671-daaf-425b-a74d-013408e1ed14    6.6G    24% /
   ├─sda14
   ├─sda15 vfat   FAT32 UEFI            1B50-CD0D                              98.2M     6% /boot/efi
   └─sda16 ext4   1.0   BOOT            ce82e1aa-5e74-4563-8892-24ec5047a744  758.1M     7% /boot
   sdb

   sda contains your operating system files. sdb is the unmounted persistent disk. GCP persistent disks' naming convention appends an english alphabet to sd in sequence for each additional disk, such as sdc, sdd, sde, and so on.

2. Create the /mnt/persistentdisk directory to mount the disk.

   CONSOLE

   Copy

   $ sudo mkdir /mnt/persistentdisk

   Explain Code

   Powered by Vultr AgentBeta

3. Mount the /dev/sdb disk to the /mnt/persistentdisk directory.

   CONSOLE

   Copy

   $ sudo mount /dev/sdb /mnt/persistentdisk

   Explain Code

   Powered by Vultr AgentBeta

   If you want to migrate data from a specific partition of your disk, you can replace the /dev/sdb device with your partition.

4. List the attached devices with additional details.

   CONSOLE

   Copy

   $ lsblk -f

   Explain Code

   Powered by Vultr AgentBeta

   Example output:

   NAME    FSTYPE LABEL           UUID                                 FSAVAIL FSUSE% MOUNTPOINT
   loop0                                                                     0   100% /snap/core20/2434
   loop1                                                                     0   100% /snap/google-cloud-cli/307
   loop2                                                                     0   100% /snap/lxd/29619
   loop3                                                                     0   100% /snap/snapd/23545
   sda
   ├─sda1  ext4   cloudimg-rootfs ba81b8eb-e557-4f1b-a83f-8e655aa5c744    7.5G    21% /
   ├─sda14
   └─sda15 vfat   UEFI            7CBD-1472                              98.3M     6% /boot/efi
   sdb     ext4                   a9955ba0-3a92-4133-bdf4-23db945af1e1    9.2G     0% /mnt/persistentdisk

   You can see that the filesystem format for the sdb Block Storage volume is ext4 and it is mounted at /mnt/persistentdisk. Note this format for use with your destination Vultr Block Storage volume.

5. Change the ownership of the mount directory and its files to your username to make the disk and its content readable and writable by your username.

   CONSOLE

   Copy

   $ sudo chown -R gcpuser:gcpuser /mnt/persistentdisk

   Explain Code

   Powered by Vultr AgentBeta

   Replace gcpuser with your actual username in the command above.

6. Navigate to the disk's mount directory.

   CONSOLE

   Copy

   $ cd /mnt/persistentdisk

   Explain Code

   Powered by Vultr AgentBeta

7. If your disk is empty, create some dummy files for testing purposes.

   CONSOLE

   Copy

   $ touch test1.txt test2.txt

   Explain Code

   Powered by Vultr AgentBeta

8. Add content to these dummy files.

   CONSOLE

   Copy

   $ echo "Hi from Vultr" | tee test1.txt test2.txt

   Explain Code

   Powered by Vultr AgentBeta

9. View disk usage and check the volume's usage ratio.

   CONSOLE

   Copy

   $ df -h

   Explain Code

   Powered by Vultr AgentBeta

   Example output:

   Filesystem      Size  Used Avail Use% Mounted on
   /dev/root       8.7G  2.3G  6.4G  27% /
   tmpfs           480M     0  480M   0% /dev/shm
   tmpfs           192M  968K  191M   1% /run
   tmpfs           5.0M     0  5.0M   0% /run/lock
   efivarfs         56K   24K   27K  48% /sys/firmware/efi/efivars
   /dev/sda16      881M   61M  759M   8% /boot
   /dev/sda15      105M  6.1M   99M   6% /boot/efi
   tmpfs            96M   12K   96M   1% /run/user/1001
   /dev/sdb        9.8G   32K  9.3G   1% /mnt/persistentdisk

   In the above output, the /dev/sdb Block Storage volume, mounted on the /mnt/persistentdisk directory, shows a 1% usage.

   You should consider the size and file format of your source device and create an appropriately sized Vultr Block Storage instance to transfer the data to.

10. To prepare your Vultr environment, access your Vultr Cloud Compute instance via SSH as a non-root sudo user, and follow the below steps:

11. List the attached devices.

    CONSOLE

    Copy

    $ lsblk -f

    Explain Code

    Powered by Vultr AgentBeta

    Example output:

    NAME   FSTYPE FSVER LABEL UUID                                 FSAVAIL FSUSE% MOUNTPOINTS
    sr0
    vda
    ├─vda1 vfat   FAT32       4873-68FE                             504.8M     1% /boot/efi
    └─vda2 ext4   1.0         0056d2d8-b1b5-4079-8941-7b85c28b4c31   39.8G    18% /
    vdb

    vdb is the unmounted Block Storage volume. vda contains your operating system files. Vultr Block Storage volumes follow the vd naming convention, with additional disks named vdc, vdd, vde, based on the number of attached volumes.

12. Format the volume with the filesystem of the source persistent disk, such as ext4.

    CONSOLE

    Copy

    $ sudo mkfs.ext4 /dev/vdb

    Explain Code

    Powered by Vultr AgentBeta

13. Create the /mnt/blockstorage directory to mount the disk.

    CONSOLE

    Copy

    $ sudo mkdir /mnt/blockstorage

    Explain Code

    Powered by Vultr AgentBeta

14. Mount the /dev/vdb volume in the /mnt/blockstorage directory.

    CONSOLE

    Copy

    $ sudo mount /dev/vdb /mnt/blockstorage

    Explain Code

    Powered by Vultr AgentBeta

15. Change the ownership of the mount directory to ensure it's writable by your non-root user.

    CONSOLE

    Copy

    $ sudo chown linuxuser:linuxuser /mnt/blockstorage

    Explain Code

    Powered by Vultr AgentBeta

    Replace linuxuser with your non-root username.

16. View disk usage and check that the volume is mounted.

    CONSOLE

    Copy

    $ df -h

    Explain Code

    Powered by Vultr AgentBeta

    Example output:

    Filesystem      Size  Used Avail Use% Mounted on
    tmpfs           197M  1.2M  196M   1% /run
    efivarfs        256K   14K  238K   6% /sys/firmware/efi/efivars
    /dev/vda2        52G  9.0G   40G  19% /
    tmpfs           982M     0  982M   0% /dev/shm
    tmpfs           5.0M     0  5.0M   0% /run/lock
    /dev/vda1       511M  6.2M  505M   2% /boot/efi
    /dev/vdb         14G   32K   13G   1% /mnt/blockstorage
    tmpfs           197M   12K  197M   1% /run/user/1002

    In the above output, the /dev/vdb Block Storage volume is mounted to the /mnt/blockstorage directory.

    If your GCP persistent disk has multiple partitions, create matching partitions on your Vultr Block Storage volume with the same filesystem format and an equal or larger size.

Migrate the Persistent Disk to Vultr Block Storage

In this section, you will migrate the files using the Rsync tool. Rsync uses SSH to securely transfer the files over an encrypted connection. In the GCP Compute instance:

1. Use the below command to start the transfer. Replace linuxuser with your Vultr Cloud Compute instance's non-root username and 192.0.2.1 with its IP address.

   CONSOLE

   Copy

   $ rsync -avz --partial --progress --exclude="lost+found" /mnt/persistentdisk/ linuxuser@192.0.2.1:/mnt/blockstorage/

   Explain Code

   Powered by Vultr AgentBeta

   Parameters of the command above do the following:

   • -a - Archive mode (preserves file structure, permissions, timestamps).
   • -v - Generates more verbose output.
   • -z - Compresses the files during data transfer.
   • --progress - Displays real-time transfer progress.
   • --partial - If the transfer interrupts, Rsync doesn't delete any not entirely transferred file.
   • --exclude="lost+found" excludes the lost+found directory from transferring to avoid permission errors and irrelevant data. The filesystem automatically generates this directory for recovery purposes and does not contain user data.

2. You will be prompted to confirm if you want to connect to the remote host. Enter yes at the prompt.

3. Enter the password of the your Vultr Cloud Compute username at the next prompt.

4. Wait for the transfer to complete. The transfer may take from several minutes to hours, depending on the data size.

   If the file transfer command interrupts or exits due to an error, execute the rsync command again and enter the SSH password to resume the transfer.

   CONSOLE

   Copy

   $ rsync -avz --partial --progress --exclude="lost+found" /mnt/persistentdisk/ linuxuser@192.0.2.1:/mnt/blockstorage/

   Explain Code

   Powered by Vultr AgentBeta

5. If you have multiple partitions in your Google Persistent disk, you can repeat this process for each one of them.

Test the Vultr Block Storage Volume

In this section, you will verify that all files transferred without any errors. You will use the Rsync file integrity check, and then create a list of checksums as an extra verification layer of integrity. You will also preview the content of files to ensure they are accessible.

1. Verify that all files transferred without errors. Replace linuxuser with your Vultr instance's non-root username and 192.0.2.1 with the Vultr instance's IP address.

   CONSOLE

   Copy

   $ rsync -avc /mnt/persistentdisk/ --exclude "lost+found" linuxuser@192.0.2.1:/mnt/blockstorage/

   Explain Code

   Powered by Vultr AgentBeta

   The command above verifies that the files transferred without errors. It re-uploads any corrupted or missing files.

2. Enter the SSH password of the Vultr instance.

   linuxuser@192.0.2.1's password:

3. Wait for the integrity check to complete.

   Example output:

   sending incremental file list

   sent 265 bytes  received 14 bytes  15.94 bytes/sec
   total size is 1,090,519,063  speedup is 3,908,670.48

4. Navigate to your user's home directory.

   CONSOLE

   Copy

   $ cd ~

   Explain Code

   Powered by Vultr AgentBeta

5. Generate a list of hash checksums of all the files in the Google Cloud persistent disk.

   CONSOLE

   Copy

   $ find /mnt/persistentdisk -type d -name "lost+found" -prune -o -type f -exec sha256sum {} \; > persistent_disk_checksums.txt

   Explain Code

   Powered by Vultr AgentBeta

   The command above skips computing checksums for the lost+found directory. Rsync didn't transfer this directory, as it is automatically generated by the filesystem for recovery purposes and does not contain user data. The command may take from minutes to hours to finish executing, depending on the data size.

   If the command above doesn't return any output, the hash list was generated.

6. Generate a list of hash checksums of all the files on the Block Storage volume and download it. Replace linuxuser with your Vultr instance's non-root username and 192.0.2.1 with the Vultr instance's IP address.

   CONSOLE

   Copy

   $ ssh linuxuser@192.0.2.1 'find /mnt/blockstorage -type d -name "lost+found" -prune -o -type f -exec sha256sum {} \;' > blockstorage_checksums.txt

   Explain Code

   Powered by Vultr AgentBeta

7. Enter the SSH password of the Vultr instance.

   linuxuser@192.0.2.1's password:

   If the command finishes without any output, it generated the hash list without errors.

8. Sort the Block Storage checksum list to make the file comparable with the other checksum file.

   CONSOLE

   Copy

   $ sort blockstorage_checksums.txt -o blockstorage_checksums.txt

   Explain Code

   Powered by Vultr AgentBeta

9. Sort the persistent disk checksum list to make the file comparable with the other checksum file.

   CONSOLE

   Copy

   $ sort persistent_disk_checksums.txt -o persistent_disk_checksums.txt

   Explain Code

   Powered by Vultr AgentBeta

10. Adjust paths in the persistent disk checksum file to match the Block Storage path structure.

    CONSOLE

    Copy

    $ sed -i 's|/mnt/persistentdisk|/mnt/blockstorage|' persistent_disk_checksums.txt

    Explain Code

    Powered by Vultr AgentBeta

    This ensures that both checksum files are comparable in the next step.

11. Compare the checksums.

    CONSOLE

    Copy

    $ diff persistent_disk_checksums.txt blockstorage_checksums.txt

    Explain Code

    Powered by Vultr AgentBeta

    If the command above returns no output, it means the files transferred without any corruption.

    Otherwise, if the command returns any output similar to below, please repeat the file transfer process by going back to the previous section. You won't have to wait for the entire process to finish again, as Rsync will only transfer the missing or corrupted files.

    3c3
    < e75bad1889255d4806f5e14838c81c4fa848b53ed8af29d1bdd517de07dad3b1  /mnt/blockstorage/test1.txt
    ---
    > e15bad1889255d4806f5e14838c81c4fa848b53ed8af29d1bdd517de07dad3b1  /mnt/blockstorage/test1.txt

    The output above means that the file test1.txt transferred with errors.

Cutover to Vultr Block Storage

Once the data is transferred successfully, you can cut over your application to use Vultr Block Storage.

• Update your application's DNS records to point to your Vultr Cloud Compute instance's IP.
• Delete your Google Persistent disk and its Compute Engine instances if they are no longer required.
• Reconfigure all applications to use the new Vultr Block Storage volume, and ensure no application uses the old persistent disk.
• Set proper file ownership and modification permissions.

Conclusion

You have migrated data from a GCP Persistent Disk to a Vultr Block Storage volume. You've used the Rsync tool to transfer the data and verified its integrity and accessibility. For more information on Vultr Block Storage, visit the official documentation.
