How to use Nextcloud with Vultr Block Storage and Object Storage

Introduction

Nextcloud is a self-hosted open-source file hosting application that lets you store, edit and share files privately using your own server. This article explains how to use Nextcloud with Vultr's Block Storage and Object Storage to maximize the application's storage potential.

Prerequisites

• Deploy a One-Click Nextcloud app from the Vultr Marketplace.
• Deploy a Block Storage volume and attach it to your server.
• Deploy an Object Storage Volume and create a new bucket.
• Create a domain pointing to the server.

1. Setup the Server

• Connect to the server using SSH and login as root.

1. Create a new server user account.

     # adduser example-user


2. Grant the new user sudo privileges.

     # adduser example-user sudo


3. Switch to the new user.

     # su example-user


4. Request a Free Let's Encrypt SSL certificate using Certbot. Replace cloud.example.com with your linked domain.

     $ sudo certbot --nginx -d cloud.example.com --agree-tos


5. To access Nextcloud using the domain, edit the config.php file.

     $ sudo nano /var/www/html/config/config.php


6. Find the trusted_domain array.

     'trusted_domains' =>
       array (
       0 => '<your-server-ip-address',
     ),


7. Add your domain as a new entry.

     'trusted_domains' =>
     array (
     0 => '<your-server-ip-address>',
     1 => 'cloud.example.com',
     ),

   Save and exit the file.

8. Restart Nginx to load changes.

     $ sudo systemctl restart nginx

Setup Nextcloud with Vultr Block Storage

2. Setup the Block Storage Volume

1. List all storage devices attached to your server.

     $ lsblk

   Output:

     NAME   MAJ:MIN RM  SIZE RO TYPE MOUNTPOINT
     loop1    7:1    0 70.3M  1 loop /snap/lxd/21029
     loop2    7:2    0 55.4M  1 loop /snap/core18/2128
     loop3    7:3    0 44.7M  1 loop /snap/snapd/15904
     loop4    7:4    0 55.5M  1 loop /snap/core18/2409
     loop5    7:5    0 61.9M  1 loop /snap/core20/1494
     loop6    7:6    0 67.8M  1 loop /snap/lxd/22753
     sr0     11:0    1 1024M  0 rom
     vda    252:0    0   25G  0 disk
     └─vda1 252:1    0   25G  0 part /
     vdb    252:16   0   40G  0 disk

   Your first block storage device displays as vdb. Any additional attachments display as vdc, vdd, and so on.

2. Set the volume disk label to gpt.

     $ sudo parted -s /dev/vdb mklabel gpt


3. Create a new primary partition occupying the full disk space.

     $ sudo parted -s /dev/vdb unit mib mkpart primary 0% 100%


4. Verify the new partition.

     $ lsblk

   Output:

     NAME   MAJ:MIN RM  SIZE RO TYPE MOUNTPOINT
     loop1    7:1    0 70.3M  1 loop /snap/lxd/21029
     loop2    7:2    0 55.4M  1 loop /snap/core18/2128
     loop3    7:3    0 44.7M  1 loop /snap/snapd/15904
     loop4    7:4    0 55.5M  1 loop /snap/core18/2409
     loop5    7:5    0 61.9M  1 loop /snap/core20/1494
     loop6    7:6    0 67.8M  1 loop /snap/lxd/22753
     sr0     11:0    1 1024M  0 rom
     vda    252:0    0   25G  0 disk
     └─vda1 252:1    0   25G  0 part /
     vdb    252:48   0   40G  0 disk
     └─vdb1 252:49   0   40G  0 part

   A new vdb1 volume with the type part should display below the main vdb disk.

5. Create a new directory in /mnt to use as a mount point for volume.

     $ sudo mkdir /mnt/nextcloud-data


6. Mount the block storage volume.

     $ sudo mount -o defaults /dev/vdb1 /mnt/nextcloud-data/


7. Verify the new volume mount point.

     $ lsblk

   Output:

     NAME   MAJ:MIN RM  SIZE RO TYPE MOUNTPOINT
     loop1    7:1    0 70.3M  1 loop /snap/lxd/21029
     loop2    7:2    0 55.4M  1 loop /snap/core18/2128
     loop3    7:3    0 44.7M  1 loop /snap/snapd/15904
     loop4    7:4    0 55.5M  1 loop /snap/core18/2409
     loop5    7:5    0 61.9M  1 loop /snap/core20/1494
     loop6    7:6    0 67.8M  1 loop /snap/lxd/22753
     sr0     11:0    1 1024M  0 rom
     vda    252:0    0   25G  0 disk
      └─vda1 252:1    0   25G  0 part /
     vdb    252:48   0   40G  0 disk
      └─vdb1 252:49   0   40G  0 part /mnt/nextdata


8. Enable persistent mounting to automatically mount the block storage volume at boot time.

     $ sudo echo /dev/vdb1 /mnt/nextcloud-data ext4 defaults,noatime,nofail 0 0 >> /etc/fstab


9. Create a sample text file in the mount directory to confirm read and write access.

     $ sudo echo "hello world, your nextcloud intergration works"> /mnt/nextcloud-data/sample.txt

3. Configure Nextcloud to use Block Storage

1. Using a web browser of your choice, visit your domain.

     https://cloud.example.com


2. Login to Nextcloud.

   If you deployed Nextcloud as a OneClick Vultr App, you can find your default credentials on the cloud instance's panel.

3. Click your username in the upper right corner and select Apps from the drop-down list.

4. Find External storage support on the Apps list and enable it.

5. Navigate to your Username again and select Settings.

6. Under the Administration section, navigate to External Storage.

7. Click Add storageand select Local from the drop-down list.

8. Enter your Mount Point in the Configuration field and click the checkmark symbol ✓ to save changes.

9. A green tick ✅ indicates a successful connection to the mount point.

4. Test

1. Navigate to Files.
2. Open the Local directory, or, select External Storage and open the block storage mount point.
3. Files stored on the block storage volume display, open the sample.txt file to confirm read access.
4. Upload files to the directory to confirm write access.

5. Setup Nextcloud with Vultr Object Storage

• Copy the Vultr Object Storage hostname.
• Copy your object storage Access and Secret Keys.

1. Through a web browser, visit your domain and Login to Nextcloud.
2. Enable the External Storage App if not already enabled.
3. Navigate to Settings, and access External Storage under the Administration section.
4. Click Add Storage and select Amazon S3 from the drop-down list.
5. Enter your Bucket name, Hostname as displayed on your Object Storage instance panel, enable SSL and leave the Port, Region fields blank.
6. Toggle the Authentication drop down and select Access Key.
7. Paste the Access Key, and Secret Key as copied from your Vultr Object Storage instance panel.
8. For easy identification, change the Folder name to Vultr Object Storage or your preferred custom label.
9. Click the checkmark symbol ✓ to save changes.
10. A green tick ✅ indicates that your Vultr Object Storage is successfully connected.

6. Test the Object Storage

1. Navigate to Files.
2. Open the Vultr Object Storage directory (as set earlier), or, navigate to External Storage and select your S3 object storage.
3. Upload or create a sample file in the directory.
4. Log in to your Vultr account, open the Object Storage panel, and confirm that the new file is available in your bucket.

7. More Information

You have successfully configured Nextcloud to use Vultr Block Storage and Object Storage volumes. You can connect multiple volumes to store different files per attachment. For more information, please visit the following resources.

• Vultr Object Storage documentation.
• Vultr Block Storage documentation.
• Nextcloud Documentation.
