Data Stream as Disjoint Intervals

Problem Statement

The goal is to design a data structure for a dynamic system that receives a flow of non-negative integers and can summarise the data in real time as a collection of disjoint intervals. The implementation focuses on building the SummaryRanges class with functionalities to add numbers to the stream and retrieve a summary of the stream as ordered, non-overlapping intervals.

This class provides:

• A constructor SummaryRanges() to initialize the system without any data.
• A method addNum(int value) to insert a new integer into the stream.
• A method getIntervals() that returns the summary of all integers input so far in the format of disjoint intervals [starti, endi], sorted by the start of each interval.

Examples

Example 1

Input:

["SummaryRanges", "addNum", "getIntervals", "addNum", "getIntervals", "addNum", "getIntervals", "addNum", "getIntervals", "addNum", "getIntervals"]
[[], [1], [], [3], [], [7], [], [2], [], [6], []]

Output:

[null, null, [[1, 1]], null, [[1, 1], [3, 3]], null, [[1, 1], [3, 3], [7, 7]], null, [[1, 3], [7, 7]], null, [[1, 3], [6, 7]]]

Explanation:

SummaryRanges summaryRanges = new SummaryRanges();
summaryRanges.addNum(1); // arr = [1]
summaryRanges.getIntervals(); // return [[1, 1]]
summaryRanges.addNum(3); // arr = [1, 3]
summaryRanges.getIntervals(); // return [[1, 1], [3, 3]]
summaryRanges.addNum(7); // arr = [1, 3, 7]
summaryRanges.getIntervals(); // return [[1, 1], [3, 3], [7, 7]]
summaryRanges.addNum(2); // arr = [1, 2, 3, 7]
summaryRanges.getIntervals(); // return [[1, 3], [7, 7]]
summaryRanges.addNum(6); // arr = [1, 2, 3, 6, 7]
summaryRanges.getIntervals(); // return [[1, 3], [6, 7]]

Constraints

• 0 <= value <= 104
• At most 3 * 104 calls will be made to addNum and getIntervals.
• At most 102 calls will be made to getIntervals.

Approach and Intuition

1. Stream Initialization

   • Through the constructor SummaryRanges(), the object is initialized. Typically, you might use a dynamic data structure such as a list or a set to handle the incoming data stream and maintain its state.

2. Adding Numbers to the Stream

   • The addNum(int value) method involves adding a number to the data structure. The main challenge here is ensuring that the addition does not disrupt the ability to efficiently generate intervals. One efficient way to handle this could be to use a tree structure or a sorted list to maintain order and facilitate the merging of intervals.

3. Generating and Retrieving Intervals

   • The getIntervals() method retrieves a summary of the data as disjoint intervals. After adding each number, you would need to check if this number bridges the gap between two existing intervals or extends an existing interval. If neither, it becomes an interval by itself.
   • To efficiently merge intervals, you can use an insertion position search (like binary search when using a sorted structure). If the added number fits within or extends an interval, modify the interval; otherwise, add a new interval.
   • Repeat interval checks and merges until no further consolidation is possible.

4. Maintaining Order and Efficiency

   • By keeping the stream's data in a sorted order and judiciously merging intervals whenever possible, the retrieval of intervals remains efficient. This ensures that each operation is done in a reasonable time, considering frequent addNum calls and relatively less frequent getIntervals calls as outlined in the constraints.

In essence, the data structure should support the dynamism of a streaming system with a focus on input order, efficient data summarization into intervals, and maintaining quick access and updates. This approach would also respect the given constraints on the number of operations and allowable input ranges.

Solutions

class IntervalManager {
    map<int, int> ranges;

public:
    IntervalManager() {}

    void insertNumber(int val) {
        int start = val, end = val;
        auto next = ranges.upper_bound(val);
        if (next != ranges.begin()) {
            auto prev = next;
            --prev;
            if (prev->second >= val) {
                return;
            }
            if (prev->second == val - 1) {
                start = prev->first;
            }
        }
        if (next != ranges.end() && next->first == val + 1) {
            end = next->second;
            ranges.erase(next);
        }
        ranges[start] = end;
    }

    vector<vector<int>> getRanges() {
        vector<vector<int>> result;
        for (const auto& interval : ranges) {
            result.push_back({interval.first, interval.second});
        }
        return result;
    }
};

class RangeModule {
    private TreeMap<Integer, Integer> ranges;

    public RangeModule() {
        ranges = new TreeMap<>();
    }

    public void addRange(int value) {
        Map.Entry<Integer, Integer> low = ranges.floorEntry(value);
        int start = value, end = value;
        if (low != null) {
            int extendLeft = low.getValue();
            if (extendLeft >= value) return;
            if (extendLeft == value - 1) start = low.getKey();
        }
        Map.Entry<Integer, Integer> high = ranges.higherEntry(value);
        if (high != null && high.getKey() == value + 1) {
            end = high.getValue();
            ranges.remove(value + 1);
        }
        ranges.put(start, end);
    }

    public int[][] getRanges() {
        int[][] result = new int[ranges.size()][2];
        int idx = 0;
        for (Map.Entry<Integer, Integer> entry : ranges.entrySet()) {
            result[idx][0] = entry.getKey();
            result[idx++][1] = entry.getValue();
        }
        return result;
    }
}
