Problem Statement
The problem is focused on processing a binary tree by sequentially removing leaf nodes through consecutive operations. Starting with a given binary tree, the objective is to:
- Identify and collect all leaf nodes of the binary tree.
- Remove these leaf nodes from the tree.
- Repeat the above two steps until the entire tree has been dismantled.
The challenge involves not just the removal of nodes, but also the collection of these nodes in the order of their removal. As trees are hierarchical structures, the repeated removal of leaf nodes simulates a peeling process where the outermost leaves are removed first, progressively reaching inwards towards the root. The result should be a list containing sub-lists of nodes, with each sub-list representing a "layer" of leaves removed during one iteration of the process.
Examples
Example 1
Input:
root = [1,2,3,4,5]
Output:
[[4,5,3],[2],[1]] Explanation: [[3,5,4],[2],[1]] and [[3,4,5],[2],[1]] are also considered correct answers since per each level it does not matter the order on which elements are returned.
Example 2
Input:
root = [1]
Output:
[[1]]
Constraints
- The number of nodes in the tree is in the range
[1, 100]
. -100 <= Node.val <= 100
Approach and Intuition
When solving the problem of collecting and removing consecutive layers of leaves from a binary tree until it is empty, we can use a level-by-level traversal approach, but inverted to target the leaf nodes specifically. Here’s the intuitive approach:
Base Trees: Understanding how even a small tree behaves can give insights into the solution. Single node trees directly lead to an answer as the root itself is a leaf. Trees with immediate children show peeling off the outer leaves first (children) before getting to the root.
Identifying Leaves: A recursive traversal typically used for tree problems, such as Depth-First Search (DFS), can be employed. During this traversal, we can identify nodes that have no children (leaf nodes) and collect them.
Storage and Removal: As leaves are identified, they need to be stored in a list as per the level of their removal. These nodes also need to be removed after they are collected, which implies restructuring the parent nodes to not reference the removed leaf nodes anymore.
Repeated Action: Once leaves of a level are collected and removed, the process repeats. This implies a loop or recursive call that ends when there are no more nodes to process (i.e., when the tree is empty).
Edge Considerations:
- Single Node: If the tree has only one node, the process stops after one collection.
- Complex Trees: The approach scales to deeper trees, given the constraints, but ensuring each level is correctly identified and processed in sequence is crucial.
By recursively stripping away the leaves, we effectively perform a breadth-first search (BFS) in a reversed manner. Each recursion or iteration peels away the outermost level, mimicking a level order traversal but from the leaves inwards.
Solutions
- C++
- Java
class Solution {
private:
vector<vector<int>> treeLevels;
public:
int calculateHeight(TreeNode *node) {
if (!node) {
return -1;
}
int left = calculateHeight(node->left);
int right = calculateHeight(node->right);
int currentHeight = max(left, right) + 1;
if (treeLevels.size() == currentHeight) {
treeLevels.push_back({});
}
treeLevels[currentHeight].push_back(node->val);
return currentHeight;
}
vector<vector<int>> gatherLeaves(TreeNode* root) {
treeLevels.clear();
calculateHeight(root);
return treeLevels;
}
};
The provided C++ solution is designed to find and segregate the leaves of a binary tree into groups according to their respective heights. The outcome is a list of lists, with each sublist containing the values of the nodes at the same height from the bottom of the tree. This solution leverages a depth-first search approach, facilitated by a recursive helper function named calculateHeight
.
- Start by defining a private class member
treeLevels
to store the resulting lists of node values organized by their heights. - Implement the
calculateHeight
function to recursively determine the height of the tree:- The function first checks if the current node is null, returning -1 if true. This condition serves as the recursion base case.
- Recursively determine the height of the left and right children.
- Compute the current node's height by taking the maximum of the left and right children's heights and adding one.
- Ensure that the
treeLevels
vector has a corresponding sublist for the current height. If not, add a new sublist. - Add the current node's value to the appropriate sublist in
treeLevels
. - Finally, return the current height.
- The
gatherLeaves
function initialisestreeLevels
and invokescalculateHeight
using the root of the binary tree, and then returns the populatedtreeLevels
.
Edit the Apache control file.
class Solution {
private List<List<Integer>> leafLevels;
private int calculateHeight(TreeNode node) {
if (node == null) {
return -1;
}
int left = calculateHeight(node.left);
int right = calculateHeight(node.right);
int height = Math.max(left, right) + 1;
if (leafLevels.size() == height) {
leafLevels.add(new ArrayList<>());
}
leafLevels.get(height).add(node.val);
return height;
}
public List<List<Integer>> findLeaves(TreeNode node) {
leafLevels = new ArrayList<>();
calculateHeight(node);
return leafLevels;
}
}
This Java solution involves a method findLeaves
within a Solution
class to determine and group the leaves of a binary tree into levels based on their height. The solution deploys a nested private method calculateHeight
utilizing a recursive approach to achieve this by performing the following steps:
- Check if the current node is null—if so, return a height of -1.
- Recursively compute the height of the left child and right child.
- Calculate the maximum height between these two and add 1 to determine the height of the current node.
- If the size of the
leafLevels
list is equal to the current node's height, add a new sublist to accommodate the current level's nodes. - Add the node's value to the corresponding sublist in
leafLevels
based on its height. - The
findLeaves
method initializesleafLevels
and callscalculateHeight
starting with the root node.
The usage of recursion allows this method to traverse through every node in the tree and classify it according to its height effectively, thereby collecting leaves at each level. The solution ensures that all leaves are classified from bottom (highest numbers) to top (lowest numbers). The result is a list of lists, where each sublist contains integers representing the values of nodes that are leaves at any given height.
