Kth Smallest Element in a BST

Updated on 05 June, 2025
Kth Smallest Element in a BST header image

Problem Statement

In this task, you are given the root node of a binary search tree (BST) and an integer k. The goal is to determine and return the kth smallest element in the tree. It's important to recognize that the values in each node of a BST follow a specific order: for any given node, the values in its left subtree are lesser, and the values in its right subtree are greater. This intrinsic ordering of BSTs is essential for efficiently finding the kth smallest element, especially considering the constraints provided.

Examples

Example 1

Input:

root = [3,1,4,null,2], k = 1

Output:

1

Example 2

Input:

root = [5,3,6,2,4,null,null,1], k = 3

Output:

3

Constraints

  • The number of nodes in the tree is n.
  • 1 <= k <= n <= 104
  • 0 <= Node.val <= 104

Approach and Intuition

To solve the problem of finding the kth smallest element in a binary search tree, consider the following logical steps:

  1. In-Order Traversal: In a BST, an in-order traversal (left-root-right) yields elements in non-decreasing order. This property makes in-order traversal particularly suitable for this problem since accessing the kth element directly gives the kth smallest value.

  2. Recursive Traversal with Early Stopping: While performing the in-order traversal:

    • If the traversal reaches the kth element, you can stop further traversal. This enhances efficiency by not traversing the entire tree if not necessary.
  3. Using an Auxiliary Data Structure:

    • You could use an array to store in-order traversal results and then directly access the kth - 1 index to retrieve the kth smallest value. However, this might not be the most space-efficient method as it requires storing potentially many node values.
  4. Iterative Deepening:

    • This involves using an iterative approach with a stack to simulate the recursive in-order traversal. This bypasses the potential stack overflow issue with deep recursion trees and usually offers more control over the traversal sequence, allowing easy retrieval of the kth element.

Examples Clarification:

  • For instance, in the first example, performing an in-order traversal on the tree rooted at [3,1,4,null,2] gives the sequence [1,2,3,4]. The first element (1-indexed) would be 1.
  • In the second example, the same in-order traversal on the tree rooted at [5,3,6,2,4,null,null,1] yields [1,2,3,4,5,6]. The third element in this ordered sequence is 3.

These examples show how following the in-order traversal and then selecting the kth element from the resultant ordered list give the required result, adhering to the constraints given. Each node's value and the range of k within the total number of elements ensure the method's applicability for all valid inputs up to the defined limits.

Solutions

  • Java
  • Python
java
class Solution {
  public int findKthSmallest(TreeNode root, int k) {
    Stack<TreeNode> treeStack = new Stack<>();

    while (true) {
      while (root != null) {
        treeStack.push(root);
        root = root.left;
      }
      root = treeStack.pop();
      if (--k == 0) return root.val;
      root = root.right;
    }
  }
}

The provided Java code efficiently finds and returns the kth smallest element in a Binary Search Tree (BST). The implementation uses an iterative approach with a stack to traverse the tree.

  • The main method findKthSmallest takes the root of the BST and an integer k as inputs.
  • A Stack<TreeNode> is initialized to manage the nodes during the in-order traversal.
  • The in-order traversal leverages the iterative approach rather than recursion for better control and to avoid the overhead of function calls.
  • Starting at the root, navigate to the leftmost node while pushing each node onto the stack.
  • Once the root is null, pop from the stack and decrement k. If k equals 0 at any point, the top value of the stack, which is the current node's value, is the kth smallest and gets returned.
  • Shift to the right child of the popped node and continue the process.

This method is time-efficient, especially in balanced BSTs, as it traverses nodes in non-decreasing order and stops as soon as the kth smallest element is found, thus not necessarily traversing the entire tree.

python
class Solution:
    def findKthSmallest(self, node: Optional[TreeNode], position: int) -> int:
        nodes = []

        while True:
            while node:
                nodes.append(node)
                node = node.left
            node = nodes.pop()
            position -= 1
            if position == 0:
                return node.val
            node = node.right

This Python 3 code defines a method to find the k-th smallest element in a Binary Search Tree (BST) using an iterative in-order traversal. The method findKthSmallest takes two parameters: a node, which is the root of the BST, and position, which indicates the k-th position of the smallest element to find. The nodes list serves as a stack to manage the tree nodes during the traversal.

The algorithm performs an iterative traversal to mimic the behavior of an in-order traversal, which naturally accesses the elements of a BST in ascending order:

  • Firstly, traverse to the leftmost node, pushing each visited node onto the stack.
  • Once you reach a leaf, backtrack by popping elements off the stack:
    • Decrease the position by one each time a node is popped.
    • Check if position is zero, which indicates the k-th smallest element has been reached. If so, return the node's value.
  • Move to the right child of the node and repeat the process until the k-th smallest element is found.

This approach avoids using recursion and manages the traversal manually with a stack, making it easy to control and understand how nodes are accessed and when the desired k-th smallest value is obtained. Additionally, this method ensures that time complexity remains efficient, specifically O(n) in the worst-case scenario, where n is the number of nodes in the tree. This is because each node is pushed and popped from the stack exactly once.
