Problem Statement

In this challenge, we are given the root node of a binary tree and are required to produce a list of all paths from the root to each leaf node. A path needs to represent the sequence of values from the root down to a leaf, where a leaf is defined as a node without any children. The paths should be written as a series of node values concatenated by "->". The function should be able to handle varying sizes and shapes of binary trees and can return the list of paths in any order.

Examples

Example 1

Input:

root = [1,2,3,null,5]

Output:

["1->2->5","1->3"]

Example 2

Input:

root = [1]

Output:

["1"]

Constraints

  • The number of nodes in the tree is in the range [1, 100].
  • -100 <= Node.val <= 100

Approach and Intuition

Understanding the problem through the examples given:

  1. Example 1:

    • Input: The tree structure is [1,2,3,null,5] which represents a binary tree where the root node 1 has two children, 2 and 3. Node 2 itself has a right child, 5, and 3 is a leaf node.
    • Output: The solution outputs two paths: "1->2->5" and "1->3". The path "1->2->5" describes the path from the root (1) to the leaf (5) via node 2, and "1->3" directly from root (1) to leaf (3).
  2. Example 2:

    • Input: The tree structure is [1], which is simply a single node that is a root as well as a leaf.
    • Output: The only path in the output is "1", which directly represents the root/leaf node.

The constraints provide us with important limits:

  • The tree can contain between 1 and 100 nodes.
  • Node values range between -100 and 100.

Given this, a straightforward approach to solving this problem would be to use a depth-first search (DFS). DFS is ideal here due to its nature of exploring as far as possible along a branch before backtracking, perfectly aligning with the requirement to explore from root to leaf. Here’s the strategy:

  1. Start at the root and initiate a path string with the root's value.
  2. Traverse the tree by going all the way down to the left and then to the right (If any) while appending the current node value to the path string.
  3. Whenever a leaf node is hit (both left and right children are null), store the current path string in the result list.
  4. Backtrack and remove the current node value from the path string, then proceed to explore remaining paths.

By following this method, the algorithm ensures all paths are properly discovered and recorded.

Solutions

  • Java
java
class Solution {
  public List<String> getAllPaths(TreeNode root) {
    LinkedList<String> allPaths = new LinkedList();
    if (root == null)
      return allPaths;

    LinkedList<TreeNode> nodes = new LinkedList();
    LinkedList<String> paths = new LinkedList();
    nodes.add(root);
    paths.add(Integer.toString(root.val));
    TreeNode currentNode;
    String currentPath;

    while (!nodes.isEmpty()) {
      currentNode = nodes.pollLast();
      currentPath = paths.pollLast();
      if (currentNode.left == null && currentNode.right == null)
        allPaths.add(currentPath);
      if (currentNode.left != null) {
        nodes.add(currentNode.left);
        paths.add(currentPath + "->" + Integer.toString(currentNode.left.val));
      }
      if (currentNode.right != null) {
        nodes.add(currentNode.right);
        paths.add(currentPath + "->" + Integer.toString(currentNode.right.val));
      }
    }
    return allPaths;
  }
}

The provided Java code solves the problem of finding all paths from the root to the leaves in a binary tree. Each path is represented as a string showing the sequence of node values, separated by arrows ("->"). Here's an overview of how the code works and how to use it:

  • Initialization of Structures:

    • A LinkedList<String> named allPaths is created to store each complete path from root to leaf as a string.
    • Two additional LinkedList instances are initialized: nodes to store the nodes of the tree, and paths to store the construction of string representations of the paths corresponding to the nodes.
  • Starting Conditions:

    • The root node is added to the nodes list, and its value is added as a starting path to the paths list.
  • Traversal Mechanism:

    • The code uses a while loop to process each node in the tree until no nodes are left to explore (i.e., nodes list is empty).
    • In each iteration, the last node (currentNode) and its corresponding path (currentPath) are retrieved and removed from their respective lists.
  • Leaf Detection:

    • If a currentNode is a leaf (both left and right children are null), currentPath is added to allPaths.
  • Path Extension:

    • If the currentNode has a left child, the child is added to nodes and the currentPath is extended (including the value of the left child) and added to paths.
    • Similarly, if a right child exists, the same process occurs for the right child.
  • Output:

    • The function returns allPaths, which contains all root-to-leaf paths in the tree.

To use this solution:

  • Define the binary tree structure with the TreeNode class that includes int val, TreeNode left, and TreeNode right.
  • Instantiate the Solution class and invoke getAllPaths method passing the root of your binary tree.
  • The method returns a list of strings, each representing a unique path from root to a leaf, following the sequence of node values.

This solution efficiently captures all paths without recursion, using iterative breadth-first search principles and thus avoids system stack overflow that might occur with deep recursion on large trees.
