Problem Statement
The n-queens puzzle is a classic combinatorial problem that involves placing n
queens on an n x n
chessboard so that no two queens threaten each other. A queen in chess can attack any piece in the same row, column, or diagonal. The solution to the puzzle requires that no two queens share the same row, column, or diagonal.
The task is to find all the unique board configurations where the queens are placed such that none of them can attack one another. Each solution should provide a distinct arrangement of the n-queens on the board, with each queen represented by 'Q'
and empty spaces represented by '.'
.
Examples
Example 1
Input:
n = 4
Output:
[[".Q..","...Q","Q...","..Q."],["..Q.","Q...","...Q",".Q.."]]
Explanation:
There exist two distinct solutions to the 4-queens puzzle as shown above
Example 2
Input:
n = 1
Output:
[["Q"]]
Constraints
1 <= n <= 9
Approach and Intuition
The n-queens puzzle can be approached using backtracking, a method that builds solutions one piece at a time and abandons a solution ("backtracks") as soon as it determines that the solution is not valid. Below is how one might think about solving the n-queens puzzle:
- Start with an empty
n x n
board. - Place a queen in the first row and in each column one by one and then proceed to the next row:
- For each placement of the queen, check if it leads to a valid configuration by ensuring no two queens attack each other.
- On the current row, if placing a queen on any column violates the attack condition with any already placed queen in previous rows (check rows, columns, and diagonals), skip placing the queen in that column.
- If a valid position is found, place the queen
('Q')
, and move to the next row. - If placing the queen in any row/column leads to a contradiction (no valid columns left in the next row), backtrack:
- Remove the queen from the current row and move the queen position in the previous row.
- Continue this process until:
- You have filled all rows successfully, at which point you add the solution to the list of solutions.
- All possible board configurations have been attempted (all combinations of rows and columns).
- Return all the distinct board configurations.
Examples and constraints lead us to understand the scale and potential edge cases for the problem:
- For
n = 1
, the solution is straightforward since only one queen on a 1x1 board doesn't have any possibility of attack. - For
n = 4
as shown in the example, the problem exhibits multiple distinct solutions, illustrating the requirement to explore various configurations. The backtracking approach efficiently navigates these while ensuring all conditions (row, column, diagonal non-attack) are met.
Given the constraints (1 <= n <= 9
), the recursive backtracking solution is computationally feasible as it effectively handles smaller boards through systematic exploration of potential placements, ensuring all solutions are found.
Solutions
- C++
- Java
- C
- JavaScript
- Python
class Solution {
private:
int boardSize;
vector<vector<string>> resultSets;
vector<string> generateBoard(vector<vector<char>> layout) {
vector<string> chessboard;
for (int i = 0; i < boardSize; ++i) {
string row(layout[i].begin(), layout[i].end());
chessboard.push_back(row);
}
return chessboard;
}
void placeQueens(int currentRow, unordered_set<int> diag,
unordered_set<int> antiDiag, unordered_set<int> columns,
vector<vector<char>> boardState) {
if (currentRow == boardSize) {
resultSets.push_back(generateBoard(boardState));
return;
}
for (int currentCol = 0; currentCol < boardSize; ++currentCol) {
int diagKey = currentRow - currentCol;
int antiDiagKey = currentRow + currentCol;
if (columns.count(currentCol) || diag.count(diagKey) ||
antiDiag.count(antiDiagKey)) {
continue;
}
columns.insert(currentCol);
diag.insert(diagKey);
antiDiag.insert(antiDiagKey);
boardState[currentRow][currentCol] = 'Q';
placeQueens(currentRow + 1, diag, antiDiag, columns, boardState);
columns.erase(currentCol);
diag.erase(diagKey);
antiDiag.erase(antiDiagKey);
boardState[currentRow][currentCol] = '.';
}
}
public:
vector<vector<string>> solveNQueens(int n) {
boardSize = n;
vector<vector<char>> initialBoard(boardSize, vector<char>(boardSize, '.'));
placeQueens(0, unordered_set<int>(), unordered_set<int>(),
unordered_set<int>(), initialBoard);
return resultSets;
}
};
The N-Queens problem is a classic algorithmic challenge that involves placing n
queens on an n x n
chessboard such that no two queens threaten each other. The provided C++ solution utilizes backtracking to explore possible valid queen placements and uses sets to track column, diagonal, and anti-diagonal attacks for efficient validation.
Key Components and their roles:
generateBoard
: Converts the current state of the chessboard from a 2D character array to a vector of strings representing each row.placeQueens
: A recursive function that attempts to place queens row by row. It uses three hash sets (columns
,diag
,antiDiag
) to check the feasibility of placing a queen in any column of the current row. The function inserts a queen if the current position is valid and recursively attempts to place the next queen.solveNQueens
: Initializes the chessboard and starts the recursive placement of queens.
Backtracking Approach Explained:
- Start from the first row and attempt to place a queen in each column.
- For each placement, calculate the corresponding diagonal and anti-diagonal keys and check against the sets. If the placement is conflict-free, recursively attempt to place a queen in the next row.
- If a queen is placed in the last row, convert the board layout into its string representation and add it to the result set.
- Backtrack by removing the queen and trying the next possible column.
- Continue this until all rows are tried.
Outcome:
The function solveNQueens
returns all possible solutions as a vector of string vectors. Each inner vector represents a unique configuration of the chessboard. This approach efficiently explores all potential configurations while pruning invalid placements early through the use of sets, significantly reducing the number of possibilities to examine.
class NQueensSolver {
private int dimension;
private List<List<String>> results = new ArrayList<>();
public List<List<String>> solveQueens(int n) {
dimension = n;
char[][] board = new char[dimension][dimension];
for (int i = 0; i < n; i++) {
for (int j = 0; j < n; j++) {
board[i][j] = '.';
}
}
search(0, new HashSet<>(), new HashSet<>(), new HashSet<>(), board);
return results;
}
private List<String> formatBoard(char[][] currentState) {
List<String> formattedBoard = new ArrayList<>();
for (int i = 0; i < dimension; i++) {
formattedBoard.add(String.valueOf(currentState[i]));
}
return formattedBoard;
}
private void search(int row, Set<Integer> diagonal, Set<Integer> antiDiagonal, Set<Integer> columns, char[][] currentState) {
if (row == dimension) {
results.add(formatBoard(currentState));
return;
}
for (int col = 0; col < dimension; col++) {
int currDiagonal = row - col;
int currAntiDiagonal = row + col;
if (columns.contains(col) || diagonal.contains(currDiagonal) || antiDiagonal.contains(currAntiDiagonal)) {
continue;
}
columns.add(col);
diagonal.add(currDiagonal);
antiDiagonal.add(currAntiDiagonal);
currentState[row][col] = 'Q';
search(row + 1, diagonal, antiDiagonal, columns, currentState);
columns.remove(col);
diagonal.remove(currDiagonal);
antiDiagonal.remove(currAntiDiagonal);
currentState[row][col] = '.';
}
}
}
The provided Java solution addresses the N-Queens problem, which involves placing N queens on an N x N chessboard so that no two queens threaten each other. The approach adopted in the solution uses backtracking, a common technique for solving constraint satisfaction problems.
Here's a concise breakdown of the code's functionality:
Class and Variables: The
NQueensSolver
class contains an instance variable for the board dimension (dimension
) and a list (results
) to store all possible arrangements that meet the conditions.Method - solveQueens(int n):
- Initializes the board with all cells set to '.' indicating that they are empty.
- Calls the
search
method from the first row onwards to place the queens.
Method - search(int row, Set<Integer> diagonal, Set<Integer> antiDiagonal, Set<Integer> columns, char[][] currentState):
- Implements a recursive function to place a queen row by row.
- Uses three sets to track which columns, diagonals, and anti-diagonals are threatened by previously placed queens.
- If a queen is placed, it recursively attempts to place further queens in subsequent rows.
- Backtracks by removing the queen and undoing the marks in the tracking sets when encountering a dead end.
Method - formatBoard(char[][] currentState):
- Converts the current state of the board configuration with queens into a list of strings to be added to the results.
This solution ensures an efficient exploration of all possible placements of queens, leveraging sets to quickly check and update the conditions required for a valid placement. The implementation efficiently manages the state without modifying the original board directly, using temporary structures to handle state during recursion.
int* columnMarkers;
int* majorDiagonal;
int* minorDiagonal;
char*** solutions;
char** chessboard;
int solutionsCount;
void search(int n, int row) {
if (row == n) {
char** boardCopy = (char**)malloc(n * sizeof(char*));
for (int i = 0; i < n; ++i) {
char* newRow = (char*)calloc(n + 1, sizeof(char));
memcpy(newRow, chessboard[i], n);
newRow[n] = '\0';
boardCopy[i] = newRow;
}
solutions[solutionsCount++] = boardCopy;
return;
}
for (int col = 0; col < n; ++col) {
if (columnMarkers[col] || majorDiagonal[col - row + n - 1] || minorDiagonal[col + row])
continue;
columnMarkers[col] = majorDiagonal[col - row + n - 1] = minorDiagonal[col + row] = 1;
chessboard[row][col] = 'Q';
search(n, row + 1);
chessboard[row][col] = '.';
columnMarkers[col] = majorDiagonal[col - row + n - 1] = minorDiagonal[col + row] = 0;
}
}
char*** solveNQueens(int n, int* returnSize, int** returnColumnSizes) {
solutionsCount = 0;
if (n < 1) {
*returnSize = 0;
return NULL;
}
solutions = (char***)malloc(n * n * n * sizeof(char**));
majorDiagonal = (int*)calloc(2 * n - 1, sizeof(int));
minorDiagonal = (int*)calloc(2 * n - 1, sizeof(int));
columnMarkers = (int*)calloc(n, sizeof(int));
chessboard = (char**)malloc(n * sizeof(char*));
for (int i = 0; i < n; ++i) {
chessboard[i] = (char*)calloc(n + 1, sizeof(char));
memset(chessboard[i], '.', n);
}
search(n, 0);
*returnSize = solutionsCount;
*returnColumnSizes = (int*)malloc(solutionsCount * sizeof(int));
for (int i = 0; i < solutionsCount; ++i) {
(*returnColumnSizes)[i] = n;
}
return solutions;
}
This comprehensive solution tackles the classic N-Queens problem using C programming language, focusing on a backtracking method to find all possible configurations where n queens can be positioned on an n x n chessboard without threatening each other. To achieve this, the solution employs arrays to track the status of columns and both diagonals for conflicts, while recursively placing queens on the board.
Here's how the solution works:
Initialize arrays for column, major diagonal, and minor diagonal checks, which help in determining if a queen can be placed without conflict.
Use recursion to attempt placing a queen in every column of each row until the board is either filled or deemed impossible for the current configuration. If a queen placement leads to a valid arrangement, the recursion proceeds to place a queen in the next row. If not, it backtracks to try new positions.
When a valid solution is found (i.e., all queens are placed), a copy of the board configuration is saved. This ensures that each unique solution is recorded.
Continue the search until all possible board configurations are explored for the given size.
Return all collected solutions along with their count and the size of each board.
This solution is memory efficient and fast, able to dynamically allocate and deallocate resources as needed during the queen placement and backtracking process. Moreover, it ensures that all potential solutions are explored thoroughly by checking all constraints before placing a queen.
var queensSolver = function (n) {
const results = [];
const initBoard = Array.from({ length: n }, () => Array(n).fill("."));
const generateBoard = (layout) => {
const board = [];
for (let i = 0; i < n; i++) {
board.push(layout[i].join(""));
}
return board;
};
const placeQueens = (row, diagonals, antiDiagonals, columns, boardState) => {
if (row === n) {
results.push(generateBoard(boardState));
return;
}
for (let col = 0; col < n; col++) {
let diag = row - col;
let antiDiag = row + col;
if (
columns.has(col) ||
diagonals.has(diag) ||
antiDiagonals.has(antiDiag)
) {
continue;
}
columns.add(col);
diagonals.add(diag);
antiDiagonals.add(antiDiag);
boardState[row][col] = "Q";
placeQueens(row + 1, diagonals, antiDiagonals, columns, boardState);
columns.delete(col);
diagonals.delete(diag);
antiDiagonals.delete(antiDiag);
boardState[row][col] = ".";
}
};
placeQueens(0, new Set(), new Set(), new Set(), initBoard);
return results;
};
The provided JavaScript function, queensSolver
, solves the N-Queens problem, where the goal is to place n
queens on an n x n chessboard so that no two queens threaten each other. The function returns all possible solutions as an array of boards, each represented as a list of strings.
- The function starts by initializing an empty board (using dots "." to signify empty spaces) and creating separate sets to track the columns, diagonals, and anti-diagonals on which queens have been placed. This helps in checking if a cell is attacked by any queen.
- Next, it defines
placeQueens
, a recursive function, that attempts to place queens row by row:- If all rows are filled (
row === n
), it converts the current board state into a readable format usinggenerateBoard
and adds it to the results. - For each cell in the current row, it checks if placing a queen is valid (i.e., the column, diagonal, and anti-diagonal are not already threatened by another queen).
- If valid, it places a queen and recursively tries to place queens in the next row.
- After returning from recursion, it backtracks by removing the queen and thus marking that position, column, diagonal, and anti-diagonal as free again.
- If all rows are filled (
The entire board search is initiated by calling placeQueens
with the initial parameters and state. The solution set results
, containing all valid configurations, is returned at the end. This approach efficiently explores all board configurations using backtracking, significantly decreasing the number of possibilities to examine by cutting off invalid paths early through the constraint checks.
class ChessSolution:
def findNQueenSolutions(self, size):
def build_board(configuration):
board_layout = []
for positions in configuration:
board_layout.append("".join(positions))
return board_layout
def search_queens(c_row, diag, anti_diag, columns, current_state):
if c_row == size:
solutions.append(build_board(current_state))
return
for c in range(size):
diag_id = c_row - c
anti_diag_id = c_row + c
if c in columns or diag_id in diag or anti_diag_id in anti_diag:
continue
columns.add(c)
diag.add(diag_id)
anti_diag.add(anti_diag_id)
current_state[c_row][c] = "Q"
search_queens(c_row + 1, diag, anti_diag, columns, current_state)
columns.remove(c)
diag.remove(diag_id)
anti_diag.remove(anti_diag_id)
current_state[c_row][c] = "."
solutions = []
init_board = [["."] * size for _ in range(size)]
search_queens(0, set(), set(), set(), init_board)
return solutions
The N-Queens problem is a well-known challenge where the goal is to place N queens on an N×N chessboard so that no two queens threaten each other. The solution involves placing one queen in each row where none can attack another using vertical, horizontal, or diagonal movements.
The provided Python solution utilizes a backtracking algorithm encapsulated within a class ChessSolution
. The findNQueenSolutions
function is the primary method that finds all possible solutions for a given board size. Here's a breakdown of how the code works:
Board Initialization:
- An N×N board is initialized with all cells set to "." indicating an empty cell.
Recursive Backtracking Function (
search_queens
):- This function attempts to place queens row by row. The current row is denoted by
c_row
. - For each column in the current row, the function checks if placing a queen there would lead to a conflict using three sets:
columns
,diag
, andanti_diag
. These sets track columns and diagonals already threatened by previously placed queens. - If a valid position is found, the queen is placed ("Q"), and the function recursively attempts to place the next queen.
- After recursive calls, it backtracks by removing the queen and clearing the threats, thereby allowing for new possibilities.
- This function attempts to place queens row by row. The current row is denoted by
Building the Board Layout:
- Once a valid configuration of queens is found for all rows, the
build_board
function converts the current state configuration into a list of strings representing the board configuration.
- Once a valid configuration of queens is found for all rows, the
Solution Collection:
- All valid board configurations are collected into the list
solutions
.
- All valid board configurations are collected into the list
When executed, the function findNQueenSolutions
returns all possible solutions as a list of N×N boards, where each board is represented as a list of strings. This implementation efficiently explores all potential board configurations using backtracking, ensuring that all solutions satisfy the conditions of the N-Queens problem.
No comments yet.
