Problem Statement
You are given a grid of size m x n
, where each cell in the grid is one of four types:
1
– The starting square (exactly one exists).2
– The ending square (exactly one exists).0
– An empty square that can be walked over.-1
– An obstacle that cannot be visited.
Your task is to determine how many unique paths exist from the starting square to the ending square such that:
- You visit every empty square exactly once.
- You can move in four directions: up, down, left, and right.
Examples
Example 1
Input:
grid = [[1,0,0,0],[0,0,0,0],[0,0,2,-1]]
Output:
2
Explanation:
There are two valid paths that visit every empty square exactly once and end at the destination.
Example 2
Input:
grid = [[1,0,0,0],[0,0,0,0],[0,0,0,2]]
Output:
4
Explanation:
Four distinct paths satisfy the conditions.
Example 3
Input:
grid = [[0,1],[2,0]]
Output:
0
Explanation:
It is not possible to visit all empty squares exactly once.
Constraints
m == grid.length
n == grid[i].length
1 <= m, n <= 20
1 <= m * n <= 20
-1 <= grid[i][j] <= 2
- Exactly one square is
1
(start) and one is2
(end)
Approach and Intuition
To solve this, we can use recursive backtracking (DFS) with the goal of visiting each empty square exactly once and reaching the ending square.
Step-by-Step Strategy
Preprocessing:
- Count the number of empty squares (value
0
) that need to be visited. - Find the coordinates of the starting square (
1
).
- Count the number of empty squares (value
Recursive DFS Traversal:
From the starting square, explore all 4 possible directions.
For each move:
- Ensure the new cell is within bounds and not an obstacle.
- Mark the cell as visited.
- Proceed recursively, decrementing the number of remaining squares to visit.
If the current cell is the ending square:
- Check if all empty squares have been visited.
- If yes, increment the valid path count.
Backtracking:
- After exploring a direction, backtrack to allow for trying alternative paths.
- Restore the grid cell to its previous state.
Return the Total Count:
- The accumulated count gives the number of unique valid paths.
Why This Works
Since the total number of cells is constrained to at most 20, this backtracking-based exhaustive search is efficient. The small size allows us to try all permutations of traversable paths without performance concerns.
Solutions
- Java
class Solution {
int rLen, cLen;
int[][] matrix;
int totalPaths;
protected void searchPaths(int r, int c, int remaining) {
if (matrix[r][c] == 2 && remaining == 1) {
totalPaths += 1;
return;
}
int tmp = matrix[r][c];
matrix[r][c] = -4;
remaining -= 1;
int[] deltasR = {0, 0, 1, -1};
int[] deltasC = {1, -1, 0, 0};
for (int i = 0; i < 4; i++) {
int newR = r + deltasR[i];
int newC = c + deltasC[i];
if (0 > newR || newR >= rLen || 0 > newC || newC >= cLen)
continue;
if (matrix[newR][newC] < 0)
continue;
searchPaths(newR, newC, remaining);
}
matrix[r][c] = tmp;
}
public int uniquePathsIII(int[][] grid) {
int freeSpaces = 0, startR = 0, startC = 0;
rLen = grid.length;
cLen = grid[0].length;
for (int r = 0; r < rLen; ++r)
for (int c = 0; c < cLen; ++c) {
int cell = grid[r][c];
if (cell >= 0)
freeSpaces += 1;
if (cell == 1) {
startR = r;
startC = c;
}
}
totalPaths = 0;
matrix = grid;
searchPaths(startR, startC, freeSpaces);
return totalPaths;
}
}
The given Java solution resolves the "Unique Paths III" problem by finding all unique paths from a start point to an endpoint on a grid while traversing all non-obstacle spaces exactly once. Below is a summary of how the solution is implemented:
Define global variables for grid dimensions (
rLen
andcLen
), the grid itself (matrix
), and to keep track of the total number of paths (totalPaths
).Implement a recursive helper function
searchPaths
:- End the recursion and increment
totalPaths
if the end cell (2
) is reached and all cells (sans obstacles) have been visited. - Mark the current cell as visited by setting it to
-4
and adjust the count of remaining cells. - Define possible moves (up, down, left, right) using two integer arrays (
deltasR
anddeltasC
). - For each possible move, check validity (cell not out of bounds or already visited) before recursively searching the grid.
- After exploring, reset the current cell to its original value to allow other paths to reuse this cell in their exploration.
- End the recursion and increment
The
uniquePathsIII
method:- Initialize counters for free spaces (non-obstacles) and determine the starting coordinates.
- Initialize the grid (
matrix
) and global variables. - Kick off the solution by calling the
searchPaths
method from the start coordinates with the total number of free spaces as the parameter to track the number of cells left to visit. - Finally, return the count of all distinct paths that span all non-obstacle cells exactly once and end at the endpoint.
This method efficiently explores all possible paths using backtracking, ensuring each valid path is counted once all constraints are satisfied. The recursive nature paired with careful state management (marking and unmarking visited cells) allows the solution to avoid revisiting configurations that have already been explored, ensuring optimal performance for larger grids.
- Python
class Explorer:
def countUniquePaths(self, matrix: List[List[int]]) -> int:
total_rows, total_columns = len(matrix), len(matrix[0])
# Initialize the variables needed for the traversal process
open_cells = 0
entry_row, entry_col = 0, 0
for r in range(total_rows):
for c in range(total_columns):
point = matrix[r][c]
if point != -1:
open_cells += 1
if point == 1:
entry_row, entry_col = r, c
# Initialize the counter for the number of valid paths
routes = 0
# Recursive function to perform the backtrack search
def backtrack(current_row, current_col, remaining):
nonlocal routes
# Check completion condition
if matrix[current_row][current_col] == 2 and remaining == 1:
# Completing the path successfully
routes += 1
return
# Mark this cell as visited
original = matrix[current_row][current_col]
matrix[current_row][current_col] = -3
remaining -= 1
# Iterate through possible moves
for delta_row, delta_col in [(0, 1), (0, -1), (1, 0), (-1, 0)]:
new_row, new_col = current_row + delta_row, current_col + delta_col
# Check bounds and cell state
if not (0 <= new_row < total_rows and 0 <= new_col < total_columns) or matrix[new_row][new_col] < 0:
continue
backtrack(new_row, new_col, remaining)
# Undo the visit
matrix[current_row][current_col] = original
backtrack(entry_row, entry_col, open_cells)
return routes
The provided Python code defines a class Explorer
which includes a method countUniquePaths
used to find all unique paths from a starting point to an endpoint in a grid, traversing every non-blocked cell exactly once. The grid cells can be free, blocked, a starting entry, or a destination and are represented as integers (0 for open, -1 for blocked, 1 for start, and 2 for end).
- The method initializes essential variables to keep track of grid dimensions, count of traversable cells, and starting position coordinates.
- Utilizes a depth-first search (DFS) technique with backtracking:
- The recursive function
backtrack
is defined withincountUniquePaths
to handle the path exploration, altering its behavior based on the current cell's value and the remaining number of cells to visit. - If the endpoint is reached and all open cells have been traversed, this valid path increments the path counter.
- To avoid revisiting cells and manage path tracing, cells are temporarily marked as visited (-3), and reverted back to their original state after recursion.
- The function explores possible moves in four directions (up, down, left, right), carefully checking boundaries and cell states to avoid moving into blocked or visited locations.
- The recursive function
- At the end of the exploration, the total number of valid paths found is returned.
This approach guarantees that all potential paths are explored while maintaining an efficient traversal of the grid by skipping over non-viable paths early. The usage of recursion and backtracking makes it a fit for smaller grids where paths are computationally feasible to enumerate.
