Set Up Virtual Hosts with Apache on Ubuntu 20.04 LTS

Web ServersApacheUbuntu
FN
Updated on November 21, 2023
Set Up Virtual Hosts with Apache on Ubuntu 20.04 LTS header image

Introduction

Apache uses virtual hosts to run more than one website on a single server with a single public IP address. You can secure and manage multiple websites on the same server by creating the appropriate permissions and ownerships in the directory structure.

In this tutorial, you'll create a virtual host environment to run multiple websites with Apache on your Ubuntu 20.04 LTS server.

Prerequisites

To complete this guide, you need the following:

  • An Vultr Ubuntu 20.04 cloud server.
  • A sudo user.
  • A LAMP Stack.
  • Domain names that point to the IP address of your VPS server. Refer to the Vultr's DNS guide to set up name servers for your domains. For demonstration purposes, this guide uses the domains example.com, example.net, and example.org.

1. Set Up a Directory Structure

  1. The default document root for Apache is /var/www. You'll need to create a separate directory for each site. Replace example.com, example.net, and example.org with the domain names of your websites.

     $ sudo mkdir -p /var/www/example.com/public_html
 $ sudo mkdir -p /var/www/example.net/public_html
 $ sudo mkdir -p /var/www/example.org/public_html

  2. The root user owns the directories you've just created. Change the ownership to the currently logged-in user. This will allow you to change the content without permission errors.

     $ sudo chown -R $USER:$USER /var/www/example.com/public_html
 $ sudo chown -R $USER:$USER /var/www/example.net/public_html
 $ sudo chown -R $USER:$USER /var/www/example.org/public_html

  3. Change the permission settings for the above directories to 755. This allows everyone, including web visitors, to have read and execute permissions on those directories and their contents. However, only the owner of the files ($USER in this case) has write permissions.

     $ sudo chmod -R 755 /var/www/example.com/public_html
 $ sudo chmod -R 755 /var/www/example.net/public_html
 $ sudo chmod -R 755 /var/www/example.org/public_html

  4. Make sure the files in these directories inherit the parent's directory group ownership.

     $ sudo find /var/www/example.com/public_html -type d -exec chmod g+s {} \;
 $ sudo find /var/www/example.net/public_html -type d -exec chmod g+s {} \;
 $ sudo find /var/www/example.org/public_html -type d -exec chmod g+s {} \;

2. Create Virtual Host Files

Create a separate virtual host configuration file under the /etc/apache2/sites-available directory for each domain you intend to host on your server.

Configure example.com

$ sudo nano /etc/apache2/sites-available/example.com.conf

Add the content below into the example.com virtual host configuration file. Provide an email address to the ServerAdmin entry. This is the contact address that Apache includes when returning an error to a client visiting your site. Issue the right path to the DocumentRoot directive. This tells Apache the directory to serve content from for any request matching the value of the ServerName. Apache records information about any errors on the ErrorLog file while the CustomLog file logs all information that occurs in your Apache server.

<VirtualHost *:80>
    ServerName example.com
    ServerAdmin admin@example.com
    DocumentRoot /var/www/example.com/public_html
    ErrorLog ${APACHE_LOG_DIR}/error.log
    CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>

Save and close the file.

Configure example.net

Create a configuration file for the example.net website.

$ sudo nano /etc/apache2/sites-available/example.net.conf

Add the content below into the example.net virtual host configuration file.

<VirtualHost *:80>
    ServerName example.net
    ServerAdmin admin@example.net
    DocumentRoot /var/www/example.net/public_html
    ErrorLog ${APACHE_LOG_DIR}/error.log
    CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>

Save and close the file.

Configure example.org

Create the third virtual host configuration file for example.org.

$ sudo nano /etc/apache2/sites-available/example.org.conf

Add the content below into the example.org virtual host configuration file.

<VirtualHost *:80>
    ServerName example.org
    ServerAdmin admin@example.org
    DocumentRoot /var/www/example.org/public_html
    ErrorLog ${APACHE_LOG_DIR}/error.log
    CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>

Save and close the file.

3. Configure and Restart Apache

Enable these host files by running the a2ensite command for each configuration file.

$ sudo a2ensite example.com.conf
$ sudo a2ensite example.org.conf
$ sudo a2ensite example.net.conf

Disable the default virtual configuration file using the a2dissite command.

$ sudo a2dissite 000-default.conf

Restart Apache to load the new configuration files.

$ sudo systemctl restart apache2

4. Create Content For the Websites

  1. Your sites are now ready to serve content. Start by creating a new HTML document for example.com.

     $ sudo nano /var/www/example.com/public_html/index.html

    Add the content below into the file.

     <html>
   <head>
     <title>This is example.com website</title>
   </head>
   <body>
     <h1>This is <b>example.com</b> website.</h1>
   </body>
 </html>

  2. Save and close the file.

  3. Create a new HTML document for example.net.

     $ sudo nano /var/www/example.net/public_html/index.html

  4. Add the content below to the file.

     <html>
   <head>
     <title>This is example.net website</title>
   </head>
   <body>
     <h1>This is <b>example.net</b> website.</h1>
   </body>
 </html>

  5. Save and close the file.

  6. Create a new HTML document for example.org.

     $ sudo nano /var/www/example.org/public_html/index.html

  7. Add the content below to the file.

     <html>
   <head>
     <title>This is example.org website</title>
   </head>
   <body>
     <h1>This is <b>example.org</b> website.</h1>
   </body>
 </html>

  8. Save and close the file.

5. Test the Websites

Visit the URLs below on a web browser. Apache webserver should now serve the right content for each site.

Conclusion

In this tutorial, you've set up virtual hosts with Apache on Ubuntu 20.04. Use the settings in this guide to run multiple websites on your single Ubuntu 20.04 VPS.

To secure your virtual hosts' websites with the Let's Encrypt SSL certificate, see the documentation below:
