Problem Statement
In this task, you are presented with the root of an N-ary tree, and your goal is to determine the diameter of this tree. The diameter is defined as the longest possible path between any two nodes within the tree. It's important to note that this path might not necessarily pass through the root. The tree is structured in N-ary format, where each node can have multiple children (not just two as in binary trees), and the tree data is typically represented by a level-order traversal, where each group of children is concluded with a null value to indicate moving to the next level.
Examples
Example 1
Input:
root = [1,null,3,2,4,null,5,6]
Output:
3
Explanation:
Diameter is shown in red color.
Example 2
Input:
root = [1,null,2,null,3,4,null,5,null,6]
Output:
4
Example 3
Input:
root = [1,null,2,3,4,5,null,null,6,7,null,8,null,9,10,null,null,11,null,12,null,13,null,null,14]
Output:
7
Constraints
- The depth of the n-ary tree is less than or equal to
1000
. - The total number of nodes is between
[1, 104]
.
Approach and Intuition
To approach the problem of finding the diameter of an N-ary tree, we can draw intuition from methods used in binary tree diameter calculations, but we must adjust for the fact that any node can have multiple children. Here's a step-by-step breakdown of a possible approach:
- Use Depth-First Search (DFS) to explore the tree. The key in DFS for this problem is to find out the maximum two depths you can achieve from any node because the potential longest path will be between these two deepest subtrees originating from the same node.
- Initiate DFS from the root. For each node, compute the depths of its subtrees.
- At each node during DFS traversal, calculate:
- The deepest path length ending at this node.
- The second deepest path length also ending at this node.
- The potential diameter at each node will be the sum of its two longest child paths (because forming a path using these two longest paths will potentially give a path longer than passing through the root or any other nodes).
- As you perform DFS and bubble up back to the root, keep track of the global maximum diameter found at any node in the tree.
- The result when the DFS completes will be this global maximum value, which represents the diameter of the tree.
The constraints that the tree depth is less than or equal to 1000 and the total number of nodes is between 1 and 10,000 ensure that this depth-first search approach will execute efficiently within practical time limits.
Solutions
- Java
- Python
class Solution {
protected int maxDiameter = 0;
protected int depthCalc(Node node, int depth) {
if (node.children.size() == 0)
return depth;
int deepest = depth, secondDeepest = 0;
for (Node child : node.children) {
int childDepth = depthCalc(child, depth + 1);
if (childDepth > deepest) {
secondDeepest = deepest;
deepest = childDepth;
} else if (childDepth > secondDeepest) {
secondDeepest = childDepth;
}
int currentDistance = deepest + secondDeepest - 2 * depth;
this.maxDiameter = Math.max(this.maxDiameter, currentDistance);
}
return deepest;
}
public int getDiameter(Node root) {
this.maxDiameter = 0;
depthCalc(root, 0);
return maxDiameter;
}
}
The provided Java solution calculates the diameter of an N-Ary tree, where the diameter is defined as the longest path between any two nodes in the tree. The code defines a Solution
class that includes methods for determining this diameter.
The primary logic involves two methods in the class:
depthCalc(Node node, int depth)
computes the depth of the tree recursively and tracks the two deepest children at each node to calculate the potential diameter at that node. It updates themaxDiameter
attribute with the largest diameter found during traversal.getDiameter(Node root)
initializes the maximum diameter to zero and starts the depth calculation from the root.
In depthCalc
, a check is made for nodes without children (leaf nodes), returning their current depth as the base case for recursion. For non-leaf nodes, the method iterates over all children to identify the deepest and the second deepest paths. These values are used to update the maxDiameter
.
Steps to calculate the diameter:
- Initialize
deepest
andsecondDeepest
for storing the maximum depths of the first two children respectively. - Traverse through all children of the current node to calculate their depths by recursive calls.
- Determine if the current child's depth surpasses the depths stored in
deepest
orsecondDeepest
, updating those variables as necessary. - Calculate the potential diameter as the sum of the two deepest paths minus double the current depth to account for the actual paths between these nodes.
- Compare and update
maxDiameter
with the newly computed diameter if it's larger. - Return the
deepest
value to the parent call, providing depth information for parent nodes to compute their diameters.
This approach ensures that the entire tree is traversed to find the longest possible path between pair of nodes, thereby determining the tree's diameter in an efficient manner using depth-first search principles.
"""
# Definition for a TreeNode with potential multiple children.
class TreeNode:
def __init__(self, value=None, children_list=None):
self.value = value
self.children = children_list if children_list is not None else []
"""
class Solution:
def maxDiameter(self, root: 'TreeNode') -> int:
"""
:type root: 'TreeNode'
:rtype: int
"""
diameter = 0
def maxDepthFromNode(node, depth):
""" Calculate max depth starting from this node all the way to the leaf nodes """
nonlocal diameter
if len(node.children) == 0:
return depth
max_1st_depth, max_2nd_depth = depth, 0
for child in node.children:
child_depth = maxDepthFromNode(child, depth + 1)
if child_depth > max_1st_depth:
max_1st_depth, max_2nd_depth = child_depth, max_1st_depth
elif child_depth > max_2nd_depth:
max_2nd_depth = child_depth
# compute the distance between the two most distant leaf nodes
path_length = max_1st_depth + max_2nd_depth - 2 * depth
diameter = max(diameter, path_length)
return max_1st_depth
maxDepthFromNode(root, 0)
return diameter
This Python solution calculates the diameter of an N-ary tree. The diameter of a tree is the length of the longest path between any two nodes in that tree.
- TreeNode Class: A custom class to structure each node of the N-ary tree. Each node has a value and a list of children nodes.
- maxDiameter Method: Computes the maximum diameter of the tree starting from the root.
- maxDepthFromNode Helper Function: This recursive function calculates the maximum depths diverging from each node to determine the longest paths possible, updating the diameter at each step. It uses two variables,
max_1st_depth
andmax_2nd_depth
, to hold the maximum two lengths found among the children to calculate potential maximum path lengths effectively. - Computing Path Length and Updating Diameter: Whenever two maximum depths are found (from any node to its descendent leaves), the potential diameter through that node (root of the subpaths) is determined.
The main function, maxDiameter
, initializes the longest diameter variable and starts the recursive depth calculation from the root. It eventually returns the maximum diameter found during the traversal. This approach ensures a comprehensive evaluation through all potential paths in the N-ary tree, comparing path lengths to determine the maximum effectively.
