How to Deploy a FastAPI Application with Gunicorn and Nginx on Ubuntu 24.04

FastAPI is a modern Python web framework for building high-performance APIs and web applications. It supports asynchronous programming using async and await, enabling efficient handling of many simultaneous client connections. Built on the ASGI (Asynchronous Server Gateway Interface) standard, FastAPI is ideal for real-time applications and remains compatible with WSGI for traditional deployments. It also offers automatic, interactive API documentation through Swagger UI, making development and testing easier and faster.

This article explains how to deploy FastAPI applications using Gunicorn as the application server and Nginx as a reverse proxy on an Ubuntu 20.04 server.

Prerequisites

• Have access to an Ubuntu 24.04 instance as a non-root sudo user
• Set up a domain A record pointing to the instance's IP address. For example, fastapi.example.com.

Setup FastAPI Application

In this section, you will create a FastAPI application inside a virtual environment. You will set up the project directory, install necessary dependencies, and test the application using the uvicorn ASGI server. Follow the steps below to setup the FastAPI application.

1. Navigate to your home directory.

   CONSOLE

   Copy

   $ cd ~

   Explain Code

   Powered by Vultr AgentBeta

2. Create a new directory for your FastAPI project.

   CONSOLE

   Copy

   $ mkdir fastapi_demo

   Explain Code

   Powered by Vultr AgentBeta

3. Navigate into the project directory.

   CONSOLE

   Copy

   $ cd fastapi_demo

   Explain Code

   Powered by Vultr AgentBeta

4. Update the APT package index.

   CONSOLE

   Copy

   $ sudo apt update

   Explain Code

   Powered by Vultr AgentBeta

5. Install the python3-venv package.

   CONSOLE

   Copy

   $ sudo apt install -y python3-venv

   Explain Code

   Powered by Vultr AgentBeta

6. Create a Python virtual environment named env.

   CONSOLE

   Copy

   $ python3 -m venv venv

   Explain Code

   Powered by Vultr AgentBeta

7. Activate the virtual environment.

   CONSOLE

   Copy

   $ source venv/bin/activate

   Explain Code

   Powered by Vultr AgentBeta

8. Install the fastapi package with all optional dependencies.

   CONSOLE

   Copy

   $ pip install fastapi[all] wheel

   Explain Code

   Powered by Vultr AgentBeta

9. Add the following FastAPI application code into the file.

   PYTHON

   Copy

   from fastapi import FastAPI
   app = FastAPI()

   @app.get("/")
   async def home():
       return {"message": "Hello World"}

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file by pressing Ctrl + X, then Enter.

10. Create a temporary web server using uvicorn.

    CONSOLE

    Copy

    $ uvicorn app:app

    Explain Code

    Powered by Vultr AgentBeta

11. Open a new terminal session and run the following command.

    CONSOLE

    Copy

    $ curl http://localhost:8000

    Explain Code

    Powered by Vultr AgentBeta

    Your output should be similar to the one below:

    {"message": "Hello World"}

Deploy FastAPI using Gunicorn

Gunicorn is a Python WSGI HTTP server for UNIX systems. It simplifies the management of FastAPI applications and supports ASGI via Uvicorn worker classes. Follow the steps below to deploy your FastAPI application using Gunicorn.

1. Install the gunicorn Python package.

   CONSOLE

   Copy

   $ pip install gunicorn

   Explain Code

   Powered by Vultr AgentBeta

2. Start a temporary Gunicorn server with the Uvicorn worker.

   CONSOLE

   Copy

   $ gunicorn app:app -k uvicorn.workers.UvicornWorker

   Explain Code

   Powered by Vultr AgentBeta

3. Open a new session and test the Gunicorn deployment using curl .

   CONSOLE

   Copy

   $ curl http://localhost:8000

   Explain Code

   Powered by Vultr AgentBeta

   Your output should be similar to the one below:

   {"message": "Hello World"}

4. Create a Gunicorn configuration file named gunicorn_conf.py.

   CONSOLE

   Copy

   $ nano gunicorn_conf.py

   Explain Code

   Powered by Vultr AgentBeta

5. Add the following code into the file.

   PYTHON

   Copy

   from multiprocessing import cpu_count

   # Socket path
   bind = 'unix:/home/linuxuser/fastapi_demo/gunicorn.sock'

   # Worker options
   workers = cpu_count() + 1
   worker_class = 'uvicorn.workers.UvicornWorker'

   # Logging options
   loglevel = 'debug'
   accesslog = '/home/linuxuser/fastapi_demo/access_log'
   errorlog = '/home/linuxuser/fastapi_demo/error_log'

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file by pressing Ctrl + X, then Enter. Replace the paths of the variables if they are different in your case.

6. Create and open the systemd unit file for the FastAPI Gunicorn service.

   CONSOLE

   Copy

   $ sudo nano /etc/systemd/system/fastapi_demo.service

   Explain Code

   Powered by Vultr AgentBeta

7. Add the following systemd service configuration to the file.

   INI

   Copy

   [Unit]
   Description=Gunicorn Daemon for FastAPI Demo Application
   After=network.target

   [Service]
   User=linuxuser
   Group=www-data
   WorkingDirectory=/home/linuxuser/fastapi_demo
   ExecStart=/home/linuxuser/fastapi_demo/venv/bin/gunicorn -c /home/linuxuser/fastapi_demo/gunicorn_conf.py app:app

   [Install]
   WantedBy=multi-user.target

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file by pressing Ctrl + X, then Enter.

8. Reload the systemd daemon.

   CONSOLE

   Copy

   $ sudo systemctl daemon-reload

   Explain Code

   Powered by Vultr AgentBeta

9. Start and enable the FastAPI Gunicorn service.

   CONSOLE

   Copy

   $ sudo systemctl enable --now fastapi_demo

   Explain Code

   Powered by Vultr AgentBeta

   Your output should be similar to the one below:

   Created symlink /etc/systemd/system/multi-user.target.wants/fastapi_demo.service → /etc/systemd/system/fastapi_demo.service.

10. View the status of newly created service.

    CONSOLE

    Copy

    $ sudo systemctl status fastapi_demo

    Explain Code

    Powered by Vultr AgentBeta

11. Test the response from the socket file using curl.

    CONSOLE

    Copy

    $ curl --unix-socket /home/linuxuser/fastapi_demo/gunicorn.sock http://localhost

    Explain Code

    Powered by Vultr AgentBeta

    Your output should be similar to the one below:

    {"message":"Hello World"}

Setup Nginx as Reverse Proxy

In this section, you will configure Nginx as a reverse proxy for your FastAPI application. Nginx is a lightweight, high-performance web server commonly used to forward client requests to application servers like Gunicorn. It allows you to serve your application on standard HTTP and HTTPS ports (80 and 443), improves request handling and performance, and supports SSL termination for secure connections.

1. Install the Nginx Web Server.

   CONSOLE

   Copy

   $ sudo apt install -y nginx

   Explain Code

   Powered by Vultr AgentBeta

2. Create a virtual host configuration.

   CONSOLE

   Copy

   $ sudo nano /etc/nginx/sites-available/fastapi_demo

   Explain Code

   Powered by Vultr AgentBeta

3. Add the following configuration. Replace fastapi.example.com with your actual domain name.

   INI

   Copy

   server {
       listen 80;
       server_name fastapi.example.com;

       location / {
           proxy_pass http://unix:/home/linuxuser/fastapi_demo/gunicorn.sock;
           proxy_set_header Host $host;
           proxy_set_header X-Real-IP $remote_addr;
           proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
           proxy_set_header X-Forwarded-Proto $scheme;

           # Optional: Handle WebSocket connections
           proxy_http_version 1.1;
           proxy_set_header Upgrade $http_upgrade;
           proxy_set_header Connection "upgrade";

           # Timeout settings
           proxy_connect_timeout 60s;
           proxy_read_timeout 120s;
       }
   }

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file with Ctrl + X, then Enter.

4. Create a symbolic link to the sites-enabled/ directory to activate the vhost.

   CONSOLE

   Copy

   $ sudo ln -s /etc/nginx/sites-available/fastapi_demo /etc/nginx/sites-enabled/

   Explain Code

   Powered by Vultr AgentBeta

5. Check the Nginx configuration syntax for any errors.

   CONSOLE

   Copy

   $ sudo nginx -t

   Explain Code

   Powered by Vultr AgentBeta

   Your output should be similar to the one below:

   nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
   nginx: configuration file /etc/nginx/nginx.conf test is successful

6. Reload the Nginx service to apply the new configuration.

   CONSOLE

   Copy

   $ sudo systemctl reload nginx

   Explain Code

   Powered by Vultr AgentBeta

7. Allow HTTP and HTTPS traffic through the firewall.

   CONSOLE

   Copy

   $ sudo ufw allow 'Nginx Full'

   Explain Code

   Powered by Vultr AgentBeta

8. Verify the firewall status to confirm the rules are applied.

   CONSOLE

   Copy

   $ sudo ufw status

   Explain Code

   Powered by Vultr AgentBeta

Secure Nginx with an SSL Certificate

To encrypt traffic and protect user data, you can secure your FastAPI application with HTTPS using a free SSL certificate from Let’s Encrypt. This section shows you how to configure SSL for your Nginx reverse proxy using Certbot.

1. Install Certbot and the Nginx plugin

   CONSOLE

   Copy

   $ sudo apt install -y certbot python3-certbot-nginx

   Explain Code

   Powered by Vultr AgentBeta

2. Request and install an SSL certificate.

   CONSOLE

   Copy

   $ sudo certbot --nginx -d fastapi.example.com

   Explain Code

   Powered by Vultr AgentBeta

   Certbot will automatically update your Nginx configuration. When prompted, enter your email address and agree to the terms of service.

3. Visit the following link in a browser to confirm SSL is working.

   https://fastapi.example.com

4. Test automatic certificate renewal.

   CONSOLE

   Copy

   $ sudo certbot renew --dry-run

   Explain Code

   Powered by Vultr AgentBeta

   If no errors appear, your SSL certificate will renew automatically every 90 days.

Conclusion

You have deployed a FastAPI application with Gunicorn and Nginx on a production ready Ubuntu server. This setup uses a Unix socket for efficient communication between Gunicorn and Nginx, and leverages systemd to manage the application as a background service. By securing Nginx with a free SSL certificate from Let’s Encrypt, you’ve ensured that all client traffic is encrypted over HTTPS. This configuration provides a robust, scalable, and secure environment for running FastAPI applications in production. For more information related to FastAPI, visit the official FastAPI website.
