How to Deploy Cassandra – Distributed NoSQL Database

Cassandra is a distributed, highly available NoSQL database designed for handling large volumes of data across multiple servers. Originally developed at Facebook, it provides linear scalability and fault tolerance with no single point of failure when deployed as a multi-node cluster. Cassandra's columnar data model and tunable consistency make it ideal for storing time-series log data where write performance and horizontal scalability are critical.

In this article, you will deploy Cassandra using Docker Compose and configure persistent storage for database files. You will access Cassandra through its CQL (Cassandra Query Language) shell to create keyspaces, tables, and manage log data.

Prerequisites

Before you begin, you need to:

• Have access to an Ubuntu 24.04-based server as a non-root user with sudo privileges.
• Install Docker and Docker Compose.

Set Up the Directory Structure and Environment Variables

In this section, you prepare the required directory structure for Cassandra and define environment variables in a .env file.

1. Create the directory structure for Cassandra.

   CONSOLE

   Copy

   $ mkdir -p ~/cassandra-logging/cassandra-data

   Explain Code

   Powered by Vultr AgentBeta

   This directory stores commit logs, data files, and hints for the Cassandra cluster.

2. Navigate into the cassandra-logging directory.

   CONSOLE

   Copy

   $ cd ~/cassandra-logging

   Explain Code

   Powered by Vultr AgentBeta

3. Set proper ownership for the Cassandra data directory. Cassandra runs as the cassandra user (UID 999) inside the container.

   CONSOLE

   Copy

   $ sudo chown -R 999:999 cassandra-data

   Explain Code

   Powered by Vultr AgentBeta

4. Create a .env file.

   CONSOLE

   Copy

   $ nano .env

   Explain Code

   Powered by Vultr AgentBeta

   Add the following variables:

   INI

   Copy

   CASSANDRA_CLUSTER_NAME=LogCluster
   CASSANDRA_DC=datacenter1
   CASSANDRA_RACK=rack1

   Explain Code

   Powered by Vultr AgentBeta

   Modify these values based on your cluster topology requirements.

   Save and close the file.

Deploy with Docker Compose

In this section, you create and deploy the Docker Compose stack that runs Cassandra. Docker Compose manages the container and applies the environment variables from your .env file.

1. Create a new Docker Compose manifest.

   CONSOLE

   Copy

   $ nano docker-compose.yaml

   Explain Code

   Powered by Vultr AgentBeta

2. Add the following content.

   YAML

   Copy

   services:
     cassandra:
       image: cassandra:latest
       container_name: cassandra
       hostname: cassandra
       ports:
         - "9042:9042"
       volumes:
         - "./cassandra-data:/var/lib/cassandra"
       environment:
         - CASSANDRA_CLUSTER_NAME=${CASSANDRA_CLUSTER_NAME}
         - CASSANDRA_DC=${CASSANDRA_DC}
         - CASSANDRA_RACK=${CASSANDRA_RACK}
         - CASSANDRA_ENDPOINT_SNITCH=GossipingPropertyFileSnitch
       restart: unless-stopped

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file.

   This deployment defines:

   • services: Single container running the database:
     • cassandra: Operates the wide-column database engine and accepts CQL protocol connections.
   • image: Official Cassandra image from Docker Hub's verified repository.
   • container_name: Fixed container identifier for consistent referencing in commands.
   • hostname: Establishes the container's network hostname used in cluster topology.
   • ports: Publishes port 9042 to the host, allowing external CQL clients to connect directly.
   • volumes: Local directory (./cassandra-data) stores all database files including SSTables, commit logs, and saved caches permanently.
   • environment: References cluster configuration from the .env file:
     • CASSANDRA_CLUSTER_NAME: Sets the cluster identifier for node association.
     • CASSANDRA_DC: Assigns the datacenter name for multi-datacenter replication strategies.
     • CASSANDRA_RACK: Designates the rack location within the datacenter for fault tolerance.
     • CASSANDRA_ENDPOINT_SNITCH: Configures topology detection for optimal replica distribution.
   • restart: unless-stopped: Automatically restarts the container on failure or reboot unless explicitly stopped.

3. Create and start the service.

   CONSOLE

   Copy

   $ docker compose up -d

   Explain Code

   Powered by Vultr AgentBeta

4. Verify that the service is running.

   CONSOLE

   Copy

   $ docker compose ps

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   NAME        IMAGE               COMMAND                  SERVICE     CREATED          STATUS                    PORTS
   cassandra   cassandra:latest    "docker-entrypoint.s…"   cassandra   25 seconds ago   Up 24 seconds (healthy)   7000-7001/tcp, 7199/tcp, 9160/tcp, 0.0.0.0:9042->9042/tcp, [::]:9042->9042/tcp

   The container is running with a healthy status. Cassandra is accepting CQL connections on port 9042.

5. Monitor Cassandra initialization logs. The database requires 30-60 seconds for initial startup.

   CONSOLE

   Copy

   $ docker compose logs

   Explain Code

   Powered by Vultr AgentBeta

   Wait until you see messages indicating the node is ready:

   INFO  [main] ... Created default superuser role 'cassandra'
   INFO  [main] ... Node localhost/127.0.0.1:7000 state jump to NORMAL

   Press Ctrl + C to exit the log view.

   For more information on managing a Docker Compose stack, see the How To Use Docker Compose article.

Access Cassandra

This section walks through validating your Cassandra setup using the CQL shell to establish a keyspace, design table structures, and insert test log records.

1. Access the CQL shell inside the container.

   CONSOLE

   Copy

   $ docker exec -it cassandra cqlsh

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   Connected to LogCluster at 127.0.0.1:9042
   [cqlsh 6.2.0 | Cassandra 5.0.2 | CQL spec 3.4.7 | Native protocol v5]
   Use HELP for help.
   cqlsh>

2. Check cluster status.

   SQL

   Copy

   cqlsh> DESCRIBE CLUSTER;

   Explain Code

   Powered by Vultr AgentBeta

   Output displays your cluster name (LogCluster) and the Cassandra version.

3. Create a keyspace for log storage. Keyspaces in Cassandra are analogous to databases in relational systems.

   SQL

   Copy

   cqlsh> CREATE KEYSPACE logs WITH replication = {'class': 'SimpleStrategy', 'replication_factor': 1};

   Explain Code

   Powered by Vultr AgentBeta

   The SimpleStrategy is appropriate for single-datacenter deployments with a replication factor of 1.

4. Use the newly created keyspace.

   SQL

   Copy

   cqlsh> USE logs;

   Explain Code

   Powered by Vultr AgentBeta

5. Create a table for application logs.

   SQL

   Copy

   cqlsh:logs> CREATE TABLE application_logs (
                 log_id UUID PRIMARY KEY,
                 timestamp TIMESTAMP,
                 level TEXT,
                 message TEXT,
                 service TEXT,
                 host TEXT
               );

   Explain Code

   Powered by Vultr AgentBeta

6. Insert a sample log entry.

   SQL

   Copy

   cqlsh:logs> INSERT INTO application_logs (log_id, timestamp, level, message, service, host)
                 VALUES (uuid(), toTimestamp(now()), 'INFO', 'Application started successfully', 'web-server', 'app-01');

   Explain Code

   Powered by Vultr AgentBeta

7. Query the log data.

   SQL

   Copy

   cqlsh:logs> SELECT * FROM application_logs;

   Explain Code

   Powered by Vultr AgentBeta

   Output displays your inserted log entry:

    log_id                               | host   | level | message                          | service    | timestamp
   --------------------------------------+--------+-------+----------------------------------+------------+---------------------------------
    cccbadb4-2b86-4e37-a500-db7be9d22942 | app-01 |  INFO | Application started successfully | web-server | 2025-12-01 17:16:07.719000+0000

8. Count total log entries.

   SQL

   Copy

   cqlsh:logs> SELECT COUNT(*) FROM application_logs;

   Explain Code

   Powered by Vultr AgentBeta

   Output:

    count
   -------
        1

9. Exit the CQL shell.

   SQL

   Copy

   cqlsh:logs> EXIT;

   Explain Code

   Powered by Vultr AgentBeta

Conclusion

You have successfully deployed Cassandra for log management with durable data persistence. This single-node deployment uses Docker Compose for reliable container orchestration with local volume storage protecting your data during restarts and upgrades. The Cassandra node operates at full capacity, prepared to receive time-series log entries through CQL drivers, manage write-heavy workloads efficiently, and expand into a multi-node cluster when horizontal scaling becomes necessary for growing log volumes.
