How to Deploy Infisical – Secrets Management Platform

Infisical is an open-source, end-to-end encrypted secret management platform. It is often viewed as a more developer-friendly alternative to HashiCorp Vault, featuring a modern dashboard, SDKs for every major programming language, and native integrations with platforms such as Vercel, AWS, and GitHub.

This article demonstrates how to deploy a production-ready Infisical instance on Ubuntu 24.04 using Docker Compose. The stack includes PostgreSQL for data storage, Redis for caching, and Traefik for automatic HTTPS termination.

Prerequisites

Before you begin:

• Have access to an Ubuntu 24.04 server as a non-root user with sudo privileges.
• Install Docker and Docker Compose.
• Configure a domain name, such as infisical.example.com, to point to your server’s public IP address.

Set Up the Directory Structure and Environment Variables

Infisical requires persistent storage for its database, cache, and certificates, along with several environment variables that define how the service operates. This section creates the necessary directory structure and prepares the .env file, including the required encryption keys.

1. Create the project folders.

   CONSOLE

   Copy

   $ mkdir -p ~/infisical/{db,redis,letsencrypt}

   Explain Code

   Powered by Vultr AgentBeta
   • db - Persistent storage for PostgreSQL (users, encrypted secrets).
   • redis - Persistent storage for the Redis queue.
   • letsencrypt - Traefik ACME certificates.

2. Navigate to the root Infisical directory.

   CONSOLE

   Copy

   $ cd ~/infisical

   Explain Code

   Powered by Vultr AgentBeta

3. Generate a random Encryption Key (128-bit, hex-encoded).

   CONSOLE

   Copy

   $ openssl rand -hex 16

   Explain Code

   Powered by Vultr AgentBeta

   Copy the output and save it for the ENCRYPTION_KEY needed in the next section.

4. Generate a random Auth Secret (256-bit, base64-encoded).

   CONSOLE

   Copy

   $ openssl rand -base64 32

   Explain Code

   Powered by Vultr AgentBeta

   Copy the output and save it for the AUTH_SECRET needed in the next section.

5. Create a file named .env in the project directory.

   CONSOLE

   Copy

   $ nano .env

   Explain Code

   Powered by Vultr AgentBeta

6. Add the following values. Paste the keys you generated in the previous step where indicated.

   INI

   Copy

   INFISICAL_DOMAIN=infisical.example.com
   LETSENCRYPT_EMAIL=admin@example.com

   # Security Keys
   ENCRYPTION_KEY=HEX_KEY_HERE
   AUTH_SECRET=BASE64_SECRET_HERE

   # Database Credentials
   POSTGRES_USER=infisical
   POSTGRES_PASSWORD=STRONG_DB_PASSWORD
   POSTGRES_DB=infisicaldb

   # Internal Connection Strings
   DB_CONNECTION_URI=postgres://${POSTGRES_USER}:${POSTGRES_PASSWORD}@db:5432/${POSTGRES_DB}
   REDIS_URL=redis://redis:6379

   Explain Code

   Powered by Vultr AgentBeta

   Replace:

   • infisical.example.com with your domain.
   • admin@example.com with your email address.
   • HEX_KEY_HERE with the hex key generated earlier.
   • BASE64_SECRET_HERE with the base64 secret.
   • STRONG_DB_PASSWORD with a secure password.

   Save and close the file.

Deploy with Docker Compose

This section defines the Docker Compose stack required to run Infisical. The deployment consists of three core components: Infisical itself, PostgreSQL, and Redis, along with Traefik for HTTPS termination. Each service is configured to run in its own container and communicate over a shared Docker network.

1. Add your user account to the docker user group.

   CONSOLE

   Copy

   $ sudo usermod -aG docker $USER

   Explain Code

   Powered by Vultr AgentBeta

2. Apply new group membership.

   CONSOLE

   Copy

   $ newgrp docker

   Explain Code

   Powered by Vultr AgentBeta

3. Create the Docker Compose manifest file.

   CONSOLE

   Copy

   $ nano docker-compose.yml

   Explain Code

   Powered by Vultr AgentBeta

4. Add the following contents:

   YAML

   Copy

   services:
     traefik:
       image: traefik:latest
       container_name: traefik
       restart: unless-stopped
       environment:
         DOCKER_API_VERSION: "1.44"
       command:
         - "--providers.docker=true"
         - "--providers.docker.exposedbydefault=false"
         - "--entrypoints.web.address=:80"
         - "--entrypoints.websecure.address=:443"
         - "--entrypoints.web.http.redirections.entrypoint.to=websecure"
         - "--entrypoints.web.http.redirections.entrypoint.scheme=https"
         - "--certificatesresolvers.le.acme.httpchallenge=true"
         - "--certificatesresolvers.le.acme.httpchallenge.entrypoint=web"
         - "--certificatesresolvers.le.acme.email=${LETSENCRYPT_EMAIL}"
         - "--certificatesresolvers.le.acme.storage=/letsencrypt/acme.json"
       ports:
         - "80:80"
         - "443:443"
       volumes:
         - /var/run/docker.sock:/var/run/docker.sock:ro
         - ./letsencrypt:/letsencrypt

     db:
       image: postgres:16-alpine
       container_name: infisical-db
       restart: unless-stopped
       environment:
         POSTGRES_USER: ${POSTGRES_USER}
         POSTGRES_PASSWORD: ${POSTGRES_PASSWORD}
         POSTGRES_DB: ${POSTGRES_DB}
       volumes:
         - ./db:/var/lib/postgresql/data

     redis:
       image: redis:alpine
       container_name: infisical-redis
       restart: unless-stopped
       environment:
         - ALLOW_EMPTY_PASSWORD=yes
       volumes:
         - ./redis:/data

     infisical:
       image: infisical/infisical:latest-postgres
       container_name: infisical
       restart: unless-stopped
       depends_on:
         - db
         - redis
       environment:
         - ENCRYPTION_KEY=${ENCRYPTION_KEY}
         - AUTH_SECRET=${AUTH_SECRET}
         - DB_CONNECTION_URI=${DB_CONNECTION_URI}
         - REDIS_URL=${REDIS_URL}
         - TELEMETRY_ENABLED=false
       labels:
         - "traefik.enable=true"
         - "traefik.http.routers.infisical.rule=Host(`${INFISICAL_DOMAIN}`)"
         - "traefik.http.routers.infisical.entrypoints=websecure"
         - "traefik.http.routers.infisical.tls=true"
         - "traefik.http.routers.infisical.tls.certresolver=le"
         - "traefik.http.services.infisical.loadbalancer.server.port=8080"

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file. This Docker Compose configuration deploys Infisical, PostgreSQL, and Redis, with Traefik handling HTTPS routing and certificate management. Each service in the stack plays a specific role:

   infisical service

   • Runs the main Infisical application using the infisical/infisical image.
   • Loads encryption keys, authentication secrets, and database/cache connection URIs from the .env file.
   • Connects to the PostgreSQL (db) and Redis (redis) services to store encrypted secrets and manage caching.
   • Includes Traefik labels that route external HTTPS traffic for your domain (${INFISICAL_DOMAIN}) to the Infisical container over port 8080.
   • Disables telemetry collection when TELEMETRY_ENABLED=false is set.

   db service (PostgreSQL)

   • Runs PostgreSQL 16 using the lightweight postgres:16-alpine image.
   • Stores Infisical application data (organizations, secrets, users, audit logs) in the ./db directory on the host.
   • Initializes the database using credentials defined in the .env file.
   • Joins the shared Traefik network so the Infisical container can access it.

   redis service

   • Runs Redis using the redis:alpine image, acting as a caching layer and message broker for Infisical.
   • Stores its in-memory persistence data in the ./redis folder.
   • Redis authentication is disabled because the container is never exposed publicly and is only accessible through Docker’s internal network. This is the default and recommended configuration for Infisical.
   • Provides the Redis endpoint referenced via REDIS_URL=redis://redis:6379.

   traefik service

   • Terminates all external HTTPS traffic and acts as a reverse proxy for the Infisical web interface.
   • Automatically obtains and renews TLS certificates from Let’s Encrypt through the ACME HTTP-01 challenge.
   • Uses Docker labels to route requests for your Infisical domain to the correct container.
   • Stores all ACME certificate data in the ./letsencrypt directory.
   • Exposes ports 80 and 443 on the host while keeping internal service ports isolated.

5. Start all services in detached mode.

   CONSOLE

   Copy

   $ docker compose up -d

   Explain Code

   Powered by Vultr AgentBeta

6. Check the container status.

   CONSOLE

   Copy

   $ docker compose ps

   Explain Code

   Powered by Vultr AgentBeta

   Wait a moment for infisical-db to initialize. The infisical container may restart once or twice during initial startup while waiting for PostgreSQL to complete initialization.

   Note

   For more information on managing a Docker Compose stack, see the How To Use Docker Compose article.

Initialize Infisical

Once the containers are running, you must set up your first administrator account.

1. Open your browser and visit your domain https://infisical.example.com. You should see a welcome page prompting you to create your first Super Admin Account.



2. Enter your First name, last name, email, and a strong password to create the initial administrative user. Click Continue to access your Infisical dashboard.

Conclusion

You have successfully deployed Infisical on Ubuntu 24.04. You now have a modern, end-to-end encrypted platform for managing secrets across your development teams and infrastructure. For more information, refer to the Infisical documentation.
