How to Install K3s with NVIDIA GPU Operator on Ubuntu 22.04

Introduction

K3s is a lightweight, fully compliant Kubernetes distribution designed for simplified deployment and operation in resource-constrained environments. With a small memory footprint and a single-binary architecture, K3s is optimized for edge computing, IoT devices, and environments where traditional Kubernetes setups may be too resource-intensive. It streamlines Kubernetes by removing non-essential features and dependencies, making it faster and easier to install while retaining all core Kubernetes functionality. K3s is particularly valued for its ease of setup and efficient management, making Kubernetes accessible in scenarios that demand a minimal, reliable, and production-ready cluster solution.

This article explains how to install and configure K3s on Vultr Cloud GPU running on Ubuntu 22.04, and set up NVIDIA GPU Operator support on your system. You will install K3s, configure Kubernetes with Helm, and set up firewall rules to enable external access to the cluster. Additionally, you will install the NVIDIA GPU Operator to manage GPU resources within K3s for optimized GPU workloads.

Prerequisites

Before you begin:

• Deploy a Vultr Cloud GPU running on Ubuntu 22.04.
• Access the server using SSH as a non-root user with sudo privileges.

Install K3s and NVIDIA GPU Operator

1. Disable the Docker system service.

   CONSOLE

   Copy

   $ sudo systemctl disable docker

   Explain Code

   Powered by Vultr AgentBeta

2. Stop the Docker system service.

   CONSOLE

   Copy

   $ sudo systemctl stop docker

   Explain Code

   Powered by Vultr AgentBeta

3. View the Docker service status and verify that it's inactive.

   CONSOLE

   Copy

   $ sudo systemctl status docker

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   ○ docker.service - Docker Application Container Engine
        Loaded: loaded (/lib/systemd/system/docker.service; disabled; vendor preset: enabled)
        Active: inactive (dead) since Wed 2024-11-06 20:45:17 UTC; 5s ago
   TriggeredBy: ● docker.socket
          Docs: https://docs.docker.com
       Process: 1088 ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock (code=exited, status=0/SUCCESS)
      Main PID: 1088 (code=exited, status=0/SUCCESS)
           CPU: 404ms

4. Install K3s.

   CONSOLE

   Copy

   $ curl -sfL https://get.k3s.io | sh -

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   [INFO]  env: Creating environment file /etc/systemd/system/k3s.service.env
   [INFO]  systemd: Creating service file /etc/systemd/system/k3s.service
   [INFO]  systemd: Enabling k3s unit
   Created symlink /etc/systemd/system/multi-user.target.wants/k3s.service → /etc/systemd/system/k3s.service.
   [INFO]  systemd: Starting k3s

5. Create a new .kube directory in your user home directory. Replace linuxuser with your actual user.

   CONSOLE

   Copy

   $ mkdir -p /home/linuxuser/.kube

   Explain Code

   Powered by Vultr AgentBeta

6. Add a k3s.yaml symbolic link to the config file in the .kube directory to set it as the default Kubernetes configuration file.

   CONSOLE

   Copy

   $ ln -s /etc/rancher/k3s/k3s.yaml /home/linuxuser/.kube/config

   Explain Code

   Powered by Vultr AgentBeta
   • ln -s /etc/rancher/k3s/k3s.yaml /home/linuxuser/.kube/config: Creates a symbolic link to the K3s Kubernetes configuration file (k3s.yaml) in the default location (/home/linuxuser/.kube/config), allowing Kubernetes CLI tools (like kubectl) to access K3s.

7. Change the .kube/config file permissions to 755 to enable Helm to load the configuration file.

   CONSOLE

   Copy

   $ sudo chmod 755 /home/linuxuser/.kube/config

   Explain Code

   Powered by Vultr AgentBeta

8. Install Helm to manage and install Kubernetes applications.

   CONSOLE

   Copy

   $ curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

   Explain Code

   Powered by Vultr AgentBeta

9. Add the NVIDIA Helm repository.

   CONSOLE

   Copy

   $ helm repo add nvidia https://helm.ngc.nvidia.com/nvidia && helm repo update

   Explain Code

   Powered by Vultr AgentBeta
   • helm repo add nvidia ...: Adds the NVIDIA Helm chart repository. This repository contains the GPU Operator and other NVIDIA tools for Kubernetes.
   • helm repo update: Updates Helm’s local repository cache, ensuring the latest package information is available.

10. Install the NVIDIA GPU Operator.

    CONSOLE

    Copy

    $ helm install --wait gpu-operator nvidia/gpu-operator --create-namespace -n gpu-operator --set driver.enabled=false

    Explain Code

    Powered by Vultr AgentBeta
    • helm install --wait gpu-operator nvidia/gpu-operator: Installs the NVIDIA GPU Operator, a Helm chart that helps manage NVIDIA GPU resources in Kubernetes.
    • --create-namespace -n gpu-operator: Creates a new namespace called gpu-operator for the GPU Operator resources.
    • --set driver.enabled=false: Installs the GPU operator without the NVIDIA driver. This is done because the driver is already installed on the system.

11. Add all required firewall rules.

    CONSOLE

    Copy

    $ sudo ufw allow 6443/tcp && sudo ufw allow 30000:32767/tcp && sudo ufw allow 30000:32767/udp

    Explain Code

    Powered by Vultr AgentBeta

12. Enable the K3s system service.

    CONSOLE

    Copy

    $ sudo systemctl enable k3s

    Explain Code

    Powered by Vultr AgentBeta

13. View the K3s service status and verify that it's running.

    CONSOLE

    Copy

    $ sudo systemctl status k3s

    Explain Code

    Powered by Vultr AgentBeta

    Output:

    ● k3s.service - Lightweight Kubernetes
     Loaded: loaded (/etc/systemd/system/k3s.service; enabled; vendor preset: enabled)
     Active: active (running) since Wed 2024-11-06 20:45:47 UTC; 7min ago
       Docs: https://k3s.io
    Main PID: 2883 (k3s-server)
      Tasks: 206
     Memory: 3.9G
        CPU: 1min 19.382s
     CGroup: /system.slice/k3s.service
     ...................................

Conclusion

In this article, you installed and configured K3s on a Vultr Cloud GPU instance running Ubuntu 22.04 and set up NVIDIA GPU Operator support. Installed K3s, and configured Helm to manage Kubernetes applications. With the firewall rules configured, your cluster is now accessible, and the NVIDIA GPU Operator is set up to manage GPU resources within K3s, enabling optimized GPU workloads. Your lightweight Kubernetes cluster is now ready for deployment, providing a scalable and efficient solution in a resource-constrained environment.
