Install WireGuard VPN Server on OpenBSD 7.0

WireGuard VPN is a free, open-source virtual private network (VPN) solution that implements modern cryptography to secure network connections. It is lightweight, fast, and easy to deploy since it uses public-key exchanges to create a VPN connection.

In this article, you install WireGuard VPN Server on OpenBSD 7.0 and configure a client connection to the server. Private addresses, 10.0.0.1/32, 10.0.0.2/32 are used as WireGuard server and client addresses, respectively. You can formulate a custom IP class for the VPN network.

Prerequisites

• Deploy an OpenBSD Server
• SSH and Login as root

Install WireGuard VPN Server.

# pkg_add wireguard-tools

Install Nano.

# pkg_add nano

Configure WireGuard Server

First, allow forwarding on your server interfaces with the following commands:

# sysctl net.inet.ip.forwarding=1
# sysctl net.inet6.ip6.forwarding=1

Output:

net.inet.ip.forwarding: 0 -> 1
net.inet6.ip6.forwarding: 0 -> 1

Add the entries to /etc/sysctl.conf.

# echo "net.inet.ip.forwarding=1" >> /etc/sysctl.conf

# echo "net.inet6.ip6.forwarding=1" >> /etc/sysctl.conf

Next, create the WireGuard configuration files directory.

# mkdir -p /etc/wireguard

Generate Keys

Change to the WireGuard configuration files directory, and set up the wg0.conf file that contains all server configurations.

# cd /etc/wireguard

Generate a new private key.

# wg genkey > private.key

Then, generate a new public key.

 # wg pubkey <private.key> public.key

Now, create the configuration file.

# touch /etc/wireguard/wg0.conf

View, and copy the private and public keys.

# cat private.key public.key

Output: (Your values should be different)

EJH+xdUPnD8WidOkV3YGcEa2kzjqgGo9n7rWmDsUimA=
1hqTUawZrVDGRu1hwTVKEFz7RaOOEh+9IWLC3+NXeFU=

Now, open and edit the configuration file using a text editor of your choice.

# nano /etc/wireguard/wg0.conf

Paste the following contents. Replace Server Private Key with the private key generated earlier. As well, enter your client IP (local for the VPN network) in the Allowed IPS = section, or simply enter 0.0.0.0/0, ::/0 to allow connections from all addresses.

[Interface]
PrivateKey = SERVER-PRIVATE-KEY
ListenPort = 51820

#Client configuration

[Peer]
PublicKey = CLIENT-PUBLIC-KEY

#Enter assigned Client local VPN address
AllowedIPs = 10.0.0.2/32

#Keep the connection alive
PersistentKeepalive = 25

Save and close the file.

Next, open and edit the firewall configuration file at /etc/pf.conf.

# nano /etc/pf.conf

Paste the following contents to allow connections and NAT traffic from the WireGuard interface.

pass in on wg0
pass in inet proto udp from any to any port 51820
pass out on egress inet from (wg0:network) nat-to (vio0:0)

Save and close the file.

Restart the firewall.

# pfctl -f /etc/pf.conf

Additionally, create a new hostname file for the WireGuard interface.

# nano /etc/hostname.wg0

Paste the following contents:

inet 10.0.0.1 255.255.255.0 NONE
up
!/usr/local/bin/wg setconf wg0 /etc/wireguard/wg0.conf

Now, activate the WireGuard interface.

# sh /etc/netstart wg0

Run ifconfig to confirm if a new wg0 interface is created.

# ifconfig wg0

Your output should be similar to:

wg0: flags=80c3<UP,BROADCAST,RUNNING,NOARP,MULTICAST> mtu 1420
index 5 priority 0 llprio 3
wgport 51820
wgpubkey PJFy3cY+LJf/YQeQ7wvLw+fSDzGy6Qu8kkLJNbrVhUk=
wgpeer YHYGb4q1AyRAINXqzndyqMW5pfqAMvJ/8nwUlS08dQk=
wgpka 25 (sec)
tx: 2072, rx: 0
wgaip 10.0.0.2/32
groups: wg
inet 10.0.0.1 netmask 0xffffff00 broadcast 10.0.0.255

Use wg to view the current WireGuard server status.

# wg

Your output should be similar to:

interface: wg0
      public key: PJFy3cY+LJf/YQeQ7wvLw+fSDzGy6Qu8kkLJNbrVhUk=
      private key: (hidden)
  listening port: 51820

peer: YHYGb4q1AyRAINXqzndyqMW5pfqAMvJ/8nwUlS08dQk=
  allowed ips: 192.168.2.2/24
      transfer: 0 B received, 2.89 KiB sent
  persistent keepalive: every 25 seconds

Optional: Configure WireGuard Client

Depending on your setup, you can configure the WireGuard client on another OpenBSD server or your local machine running Windows, macOS, Linux. For purposes of this article, set up WireGuard client on another OpenBSD and test the connection.

Repeat all the above WireGuard server configuration steps and only change values in the wg0.conf file. Also, assign a different local IP Address 10.0.0.2/32 in your hostname.wg0 file.

Generate client keys.

# wg genkey > private.key

#wg pubkey <private.key> public.key

Edit the WireGuard configuration file.

# nano /etc/wireguard/wg0.conf

Paste the following contents:

 [Interface]
PrivateKey = CLIENT-Private-Key

[Peer]
PublicKey = Server-Public-Key
Endpoint = Server-IP:51820 #Your Vultr Server Public IP Address
AllowedIPs = 0.0.0.0/0, ::/0

Enter the generated client private key, then enter the server public key copied earlier. In the EndPoint = section, enter your OpenBSD public IP Address.

Edit the hostname.wg0 file.

#nano /etc/hostname.wg0

Paste the following code:

inet 10.0.0.2 255.255.255.0 NONE
up

!/usr/local/bin/wg setconf wg0 /etc/wireguard/wg0.conf

Save and close the file.

Activate the Interface.

# sh /etc/netstart wg0

Edit your firewall configuration file.

 # nano /etc/pf.conf

Paste the following rules:

pass out on egress inet from (wg0:network) nat-to (vio0:0)

Save and close the file.

Restart Firewall.

# pfctl -f /etc/pf.conf

To add new clients on the server, simply repeat the above processes, and include a new [peer] section for every client.

Test your WireGuard VPN Server

Your WireGuard VPN Server is up and forwarding packets on your OpenBSD server. Depending on your client computer (whether another server or local computer), test your VPN by pinging your server.

# ping Your-WireGuard-Server-Public-IP

On the server machine, run wg to view the connection details.

# wg

Your output should be similar to:

interface: wg0
      public key: PJFy3cY+LJf/YQeQ7wvLw+fSDzGy6Qu8kkLJNbrVhUk=
      private key: (hidden)
      listening port: 51820

peer: 1tav0yogeBSLQ0D/Y8XhJXxUy6aYzqgNbM+avuH59nE=
      endpoint: 41.75.188.192:46467
      allowed ips: 10.0.0.2/32
      latest handshake: 1 minute, 44 seconds ago
      transfer: 11.68 MiB received, 68.65 MiB sent
      persistent keepalive: every 25 seconds

Traffic from the client machine is indicated as transfer: received.

Conclusion

You have successfully set up WireGuard VPN server on OpenBSD, all connected clients will have Internet access through the server. Note that the 10.0.0.0/32 addresses are not provided by Vultr, but rather created for the VPN network. To learn more about WireGuard VPN, consider viewing the official documentation.
