How to Deploy Tempo – Distributed Tracing Backend

Tempo is an open-source distributed tracing backend that stores and queries traces from your applications. It integrates seamlessly with distributed systems to help you understand request flows, identify performance bottlenecks, and troubleshoot issues across microservices architectures. Tempo requires only object storage and is designed for cost-efficient, high-volume trace data.

In this article, you will deploy Tempo using Docker Compose, configure persistent storage for trace data, and set up Traefik as a reverse proxy to securely access your Tempo instance.

Prerequisites

Before you begin, you need to:

• Have access to an Ubuntu 24.04-based server as a non-root user with sudo privileges.
• Install Docker and Docker Compose.
• Configure a domain A record pointing to your server's IP address (for example, tempo.example.com).

Set Up the Directory Structure and Environment Variables

In this section, you prepare the required directory structure for Tempo and define environment variables in a .env file.

1. Create the directory structure for Tempo.

   CONSOLE

   Copy

   $ mkdir -p ~/tempo-tracing/{tempo-data,tempo-config}

   Explain Code

   Powered by Vultr AgentBeta

   These directories store Tempo's trace blocks and configuration files.

2. Navigate into the tempo-tracing directory.

   CONSOLE

   Copy

   $ cd ~/tempo-tracing

   Explain Code

   Powered by Vultr AgentBeta

3. Set proper ownership for the Tempo data directory. Tempo runs as the tempo user (UID 10001) inside the container.

   CONSOLE

   Copy

   $ sudo chown -R 10001:10001 tempo-data

   Explain Code

   Powered by Vultr AgentBeta

4. Create a .env file.

   CONSOLE

   Copy

   $ nano .env

   Explain Code

   Powered by Vultr AgentBeta

   Add the following variables:

   INI

   Copy

   DOMAIN=tempo.example.com
   LETSENCRYPT_EMAIL=admin@example.com

   Explain Code

   Powered by Vultr AgentBeta

   Replace:

   • tempo.example.com with your domain.
   • admin@example.com with your email.

   Save and close the file.

5. Create a Tempo configuration file.

   CONSOLE

   Copy

   $ nano tempo-config/tempo-config.yaml

   Explain Code

   Powered by Vultr AgentBeta

6. Add the following content.

   YAML

   Copy

   server:
     http_listen_port: 3200

   distributor:
     receivers:
       jaeger:
         protocols:
           thrift_http:
           grpc:
       otlp:
         protocols:
           http:
           grpc:

   storage:
     trace:
       backend: local
       local:
         path: /var/tempo/traces
       wal:
         path: /var/tempo/wal

   compactor:
     compaction:
       block_retention: 168h

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file.

   This configuration enables trace ingestion via Jaeger and OpenTelemetry protocols, configures local filesystem storage for trace data, and sets a 7-day retention period. The distributor accepts traces in multiple formats while the storage backend persists them to the mounted data directory.

Deploy with Docker Compose

In this section, you create and deploy the Docker Compose stack that runs Tempo behind Traefik. Docker Compose manages both containers, applies the environment variables from your .env file, and automatically configures HTTPS routing through Traefik.

1. Create a new Docker Compose manifest.

   CONSOLE

   Copy

   $ nano docker-compose.yaml

   Explain Code

   Powered by Vultr AgentBeta

2. Add the following content.

   YAML

   Copy

   services:
     traefik:
       image: traefik:v3.6
       container_name: traefik
       command:
         - "--providers.docker=true"
         - "--providers.docker.exposedbydefault=false"
         - "--entrypoints.web.address=:80"
         - "--entrypoints.websecure.address=:443"
         - "--entrypoints.web.http.redirections.entrypoint.to=websecure"
         - "--entrypoints.web.http.redirections.entrypoint.scheme=https"
         - "--certificatesresolvers.letsencrypt.acme.httpchallenge=true"
         - "--certificatesresolvers.letsencrypt.acme.httpchallenge.entrypoint=web"
         - "--certificatesresolvers.letsencrypt.acme.email=${LETSENCRYPT_EMAIL}"
         - "--certificatesresolvers.letsencrypt.acme.storage=/letsencrypt/acme.json"
       ports:
         - "80:80"
         - "443:443"
       volumes:
         - "letsencrypt:/letsencrypt"
         - "/var/run/docker.sock:/var/run/docker.sock:ro"
       restart: unless-stopped

     tempo:
       image: grafana/tempo:latest
       container_name: tempo
       hostname: tempo
       expose:
         - "3200"
         - "4317"
         - "4318"
         - "14250"
         - "14268"
       volumes:
         - "./tempo-config/tempo-config.yaml:/etc/tempo/tempo.yaml"
         - "./tempo-data:/var/tempo"
       command: -config.file=/etc/tempo/tempo.yaml
       labels:
         - "traefik.enable=true"
         - "traefik.http.routers.tempo.rule=Host(`${DOMAIN}`)"
         - "traefik.http.routers.tempo.entrypoints=websecure"
         - "traefik.http.routers.tempo.tls.certresolver=letsencrypt"
         - "traefik.http.services.tempo.loadbalancer.server.port=3200"
       restart: unless-stopped

   volumes:
     letsencrypt:

   Explain Code

   Powered by Vultr AgentBeta

   Save and close the file.

   Key components in this configuration:

   • services: Two cooperating containers implement the tracing backend:
     • traefik: Handles HTTP/HTTPS traffic, automatically obtains Let's Encrypt certificates, and proxies requests to Tempo.
     • tempo: Collects trace spans, archives them for querying, and exposes APIs for retrieval.
   • image: Container registries on Docker Hub supply the official images.
   • container_name: Static naming facilitates service identification during debugging and administrative operations.
   • command (Traefik): Establishes behavior including Docker integration, port configuration (80/443), protocol enforcement (HTTPS), and automated Let's Encrypt certificate requests via HTTP validation.
   • command (Tempo): Identifies the configuration file path for service initialization.
   • ports (Traefik): Binds host ports 80 and 443 for client connectivity.
   • expose (Tempo): Makes multiple ports accessible within the container network without public exposure. Port 3200 handles HTTP queries, while ports 4317, 4318, 14250, and 14268 receive trace data from different protocol implementations.
   • volumes:
     • File system mounts ensure configuration and trace storage persists beyond container lifecycles.
     • Certificate information survives container recreation through the letsencrypt named volume.
     • Traefik accesses Docker's control socket to perform automatic service detection and routing updates.
   • labels (Tempo): Traefik routing metadata that enables proxy behavior, associates domain names with backends, designates the TLS provider, and specifies port 3200 for load balancing.
   • restart: unless-stopped: Maintains service continuity by auto-restarting containers following failures or reboots, except when manually terminated.

3. Create and start the services.

   CONSOLE

   Copy

   $ docker compose up -d

   Explain Code

   Powered by Vultr AgentBeta

4. Verify that the services are running.

   CONSOLE

   Copy

   $ docker compose ps

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   NAME      IMAGE                  COMMAND                  SERVICE   CREATED          STATUS          PORTS
   tempo     grafana/tempo:latest   "/tempo -config.file…"   tempo     18 seconds ago   Up 17 seconds   3200/tcp, 4317/tcp, 4318/tcp, 14250/tcp, 14268/tcp
   traefik   traefik:v3.6           "/entrypoint.sh --pr…"   traefik   18 seconds ago   Up 17 seconds   0.0.0.0:80->80/tcp, [::]:80->80/tcp, 0.0.0.0:443->443/tcp, [::]:443->443/tcp

   Both containers are running successfully. Tempo is ready to accept trace data while Traefik accepts connections on ports 80 and 443.

5. View the logs of the services.

   CONSOLE

   Copy

   $ docker compose logs

   Explain Code

   Powered by Vultr AgentBeta

   For more information on managing a Docker Compose stack, see the How To Use Docker Compose article.

Access Tempo

In this section, you access the Tempo API to verify your installation by checking service readiness and querying available trace endpoints.

1. Check the service readiness endpoint.

   CONSOLE

   Copy

   $ curl https://tempo.example.com/ready

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   ready

   This confirms Tempo is operational and accepting requests.

2. Query the service status to view configuration details.

   CONSOLE

   Copy

   $ curl https://tempo.example.com/status

   Explain Code

   Powered by Vultr AgentBeta

   Output displays Tempo's current configuration, including enabled modules, storage backend, and ingestion settings. This endpoint is useful for verifying your deployment configuration.

3. Check the build information to verify the Tempo version.

   CONSOLE

   Copy

   $ curl https://tempo.example.com/api/status/buildinfo

   Explain Code

   Powered by Vultr AgentBeta

   Output:

   {"version":"v2.9.0","revision":"032d47627","branch":"main","buildUser":"","buildDate":"","goVersion":"go1.25.1"}

   This confirms Tempo is responding correctly to API requests and displays version information for troubleshooting purposes.

Conclusion

You have successfully deployed Tempo for distributed tracing with HTTPS encryption. The Docker Compose architecture delivers both the tracing backend and reverse proxy with filesystem persistence ensuring trace data durability. Let's Encrypt automation maintains valid certificates while Traefik performs intelligent traffic management. Tempo now stands ready to accept distributed trace spans from microservices using Jaeger, OpenTelemetry, or alternative instrumentation frameworks through its protocol-agnostic ingestion APIs.
