Elasticsearch is a distributed search and analytics engine built on Apache Lucene. It provides near real-time search capabilities for structured and unstructured data, making it ideal for log aggregation, full-text search, and business analytics. Elasticsearch scales horizontally across multiple nodes and supports complex queries through its RESTful API.

In this article, you will deploy Elasticsearch using Docker Compose, configure persistent storage for indexed data, and set up Traefik as a reverse proxy to securely access your Elasticsearch instance.

Prerequisites

Before you begin, you need to:

• Have access to an Ubuntu 24.04-based server as a non-root user with sudo privileges.
• Install Docker and Docker Compose.
• Configure a domain A record pointing to your server's IP address (for example, elasticsearch.example.com).

Set Up the Directory Structure and Environment Variables

In this section, you prepare the required directory structure for Elasticsearch and define environment variables in a .env file.

1. Create the directory structure for Elasticsearch.

   console Copy

   $ mkdir -p ~/elasticsearch-logging/{elasticsearch-data,elasticsearch-config}


   Explain Code

   These directories serve different purposes:

   • elasticsearch-data: Stores indexed data, including shards and segments.
   • elasticsearch-config: Contains YAML configuration files.

2. Navigate into the elasticsearch-logging directory.

   console Copy

   $ cd ~/elasticsearch-logging


   Explain Code

3. Set proper ownership for the Elasticsearch data directory. Elasticsearch runs as the elasticsearch user (UID 1000) inside the container.

   console Copy

   $ sudo chown -R 1000:1000 elasticsearch-data


   Explain Code

   You can verify this UID by running docker run --rm elasticsearch:8.17.0 id.

4. Create a .env file.

   console Copy

   $ nano .env


   Explain Code

   Add the following variables:

   ini Copy

   DOMAIN=elasticsearch.example.com
   LETSENCRYPT_EMAIL=admin@example.com


   Explain Code

   Replace:

   • elasticsearch.example.com with your domain.
   • admin@example.com with your email.

   Save and close the file.

5. Create an Elasticsearch configuration file.

   console Copy

   $ nano elasticsearch-config/elasticsearch.yml


   Explain Code

6. Add the following content.

   yaml Copy

   cluster.name: logging-cluster
   node.name: node-1
   network.host: 0.0.0.0
   http.port: 9200
   discovery.type: single-node
   xpack.security.enabled: false


   Explain Code

   Save and close the file.

   The configuration includes:

   • cluster.name: Identifies this Elasticsearch cluster for node discovery.
   • node.name: Assigns a unique identifier to this node.
   • network.host: Configures Elasticsearch to listen on all network interfaces, allowing Traefik to connect from the Docker network.
   • discovery.type: Configures single-node mode, disabling cluster formation requirements.
   • xpack.security.enabled: Disables authentication for simplified initial deployment.

Deploy with Docker Compose

In this section, you create and deploy the Docker Compose stack that runs Elasticsearch behind Traefik. Docker Compose manages both containers, applies the environment variables from your .env file, and automatically configures HTTPS routing through Traefik.

1. Create a new Docker Compose manifest.

   console Copy

   $ nano docker-compose.yaml


   Explain Code

2. Add the following content.

   yaml Copy

   services:
     traefik:
       image: traefik:v3.6
       container_name: traefik
       command:
         - "--providers.docker=true"
         - "--providers.docker.exposedbydefault=false"
         - "--entrypoints.web.address=:80"
         - "--entrypoints.websecure.address=:443"
         - "--entrypoints.web.http.redirections.entrypoint.to=websecure"
         - "--entrypoints.web.http.redirections.entrypoint.scheme=https"
         - "--certificatesresolvers.letsencrypt.acme.httpchallenge=true"
         - "--certificatesresolvers.letsencrypt.acme.httpchallenge.entrypoint=web"
         - "--certificatesresolvers.letsencrypt.acme.email=${LETSENCRYPT_EMAIL}"
         - "--certificatesresolvers.letsencrypt.acme.storage=/letsencrypt/acme.json"
       ports:
         - "80:80"
         - "443:443"
       volumes:
         - "letsencrypt:/letsencrypt"
         - "/var/run/docker.sock:/var/run/docker.sock:ro"
       restart: unless-stopped

     elasticsearch:
       image: docker.elastic.co/elasticsearch/elasticsearch:9.2.0
       container_name: elasticsearch
       hostname: elasticsearch
       expose:
         - "9200"
       volumes:
         - "./elasticsearch-config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml"
         - "./elasticsearch-data:/usr/share/elasticsearch/data"
       environment:
         - "ES_JAVA_OPTS=-Xms512m -Xmx512m"
       labels:
         - "traefik.enable=true"
         - "traefik.http.routers.elasticsearch.rule=Host(`${DOMAIN}`)"
         - "traefik.http.routers.elasticsearch.entrypoints=websecure"
         - "traefik.http.routers.elasticsearch.tls.certresolver=letsencrypt"
       restart: unless-stopped

   volumes:
     letsencrypt:


   Explain Code

   Save and close the file.

   This manifest specifies:

   • services: Defines two containers working together:
     • traefik: Accepts external connections, provisions SSL/TLS certificates automatically, and routes requests to backend services.
     • elasticsearch: Runs the core search engine, indexes documents, and responds to queries.
   • image: Specifies container images from Docker Hub and the official Elastic registry.
   • container_name: Assigns fixed names for easier log inspection and container management.
   • command (Traefik): Configures Docker provider integration, HTTP/HTTPS entry points on ports 80 and 443, forced HTTPS redirects, and automated Let's Encrypt certificate generation using HTTP challenge validation.
   • ports (Traefik): Binds ports 80 (HTTP) and 443 (HTTPS) on the host to receive incoming traffic.
   • expose (Elasticsearch): Makes port 9200 accessible only within the Docker network, preventing direct public access.
   • volumes:
     • Local directories (./elasticsearch-config, ./elasticsearch-data) mount into containers to persist configuration and search indexes.
     • The letsencrypt named volume stores certificate data permanently.
     • Mounting /var/run/docker.sock grants Traefik read-only access for automatic service discovery.
   • environment (Elasticsearch): Sets JVM memory limits to 512MB minimum and maximum for stable resource usage.
   • labels (Elasticsearch): Traefik routing rules that activate the reverse proxy, match requests by hostname, and apply Let's Encrypt TLS certificates.
   • restart: unless-stopped: Automatically restarts containers after crashes or server reboots, except when manually stopped.

3. Create and start the services.

   console Copy

   $ docker compose up -d


   Explain Code

4. Verify that the services are running.

   console Copy

   $ docker compose ps


   Explain Code

   Output:

   NAME            IMAGE                                                  COMMAND                  SERVICE         CREATED          STATUS          PORTS
   elasticsearch   docker.elastic.co/elasticsearch/elasticsearch:9.2.0    "/bin/tini -- /usr/l…"   elasticsearch   22 seconds ago   Up 21 seconds   9200/tcp
   traefik         traefik:v3.6                                           "/entrypoint.sh --pr…"   traefik         22 seconds ago   Up 21 seconds   0.0.0.0:80->80/tcp, [::]:80->80/tcp, 0.0.0.0:443->443/tcp, [::]:443->443/tcp

   Both containers are running. Elasticsearch processes search requests while Traefik handles incoming connections on ports 80 and 443.

5. View the logs of the services.

   console Copy

   $ docker compose logs


   Explain Code

   For more information on managing a Docker Compose stack, see the How To Use Docker Compose article.

Access Elasticsearch

This section demonstrates verification of your Elasticsearch installation through cluster health checks and test index creation to validate search and storage functionality.

1. Access the Elasticsearch API in your browser.

   https://elasticsearch.example.com

   You should see a JSON response with cluster information including the version number and cluster UUID.

2. Check cluster health using the command line.

   console Copy

   $ curl https://elasticsearch.example.com/_cluster/health?pretty


   Explain Code

   Output:

   {
     "cluster_name" : "logging-cluster",
     "status" : "green",
     "number_of_nodes" : 1,
     "number_of_data_nodes" : 1
   }

   A green status indicates the cluster is healthy and operational.

3. Create a test index to verify data storage.

   console Copy

   $ curl -X PUT "https://elasticsearch.example.com/test-index" -H 'Content-Type: application/json' -d'
   {
     "settings": {
       "number_of_shards": 1,
       "number_of_replicas": 0
     }
   }'


   Explain Code

   Output:

   {"acknowledged":true,"shards_acknowledged":true,"index":"test-index"}

4. Index a sample document.

   console Copy

   $ curl -X POST "https://elasticsearch.example.com/test-index/_doc" -H 'Content-Type: application/json' -d'
   {
     "message": "Hello Elasticsearch",
     "timestamp": "2025-12-01T19:32:43Z"
   }'


   Explain Code

5. Search for the document.

   console Copy

   $ curl "https://elasticsearch.example.com/test-index/_search?pretty"


   Explain Code

   The output displays your indexed document, confirming that Elasticsearch can store and retrieve data successfully.

Conclusion

You have successfully deployed Elasticsearch for log management with HTTPS encryption. This Docker Compose implementation combines the search engine with an automatic SSL reverse proxy, while volume mounts preserve indexed data through container updates and restarts. Let's Encrypt integration maintains valid certificates automatically as Traefik routes incoming requests securely. Your Elasticsearch instance now stands ready to ingest application logs, perform full-text searches across massive datasets, and deliver real-time analytics through its RESTful API.
